Aquagem DE14 - Technical Specifications; OVERALL DIMENSION (MM)

3
2. TECHNICAL SPECIFICATIONS
3. OVERALL DIMENSION (mm)
Model
Advised Pool
Volume
(m³)
P1
Voltage
(V/Hz)
Qmax
(m³/h)
Hmax
(m)
Circulation (m³/h)
KW At 10m At 8m
DE14 20-40 0.60
220-240/
50/60
18.0 14.0 9.0 14.0
DE18 30-50 0.75
21.0 16.0 14.0 18.0
DE22 40-70 1.00
25.5 18.0 18.0 22.0
DE28 60-90 1.50
31.0 20.5 28.0 30.0
Figure 1
