NIGHT GLOW LIGHTING SYSTEMS
ASSEMBLY INSTRUCTIONS
(Pictures used for representational purposes, may not depict actual product)
Check to see that all light xture retaining bands are in place. To install the retaining
bands follow the instructions below, to install light xtures, skip to step 2.
1. To install light xture retaining band on existing oat:
a. Place the unit on level surface with motor down and oat up.
b. Place one bent leg in oat slot as shown.
c. Maneuver the leg into the slot as far as it will go.
d. Work second bent leg into the other slot.
e. Center the clip over opening and bolt into place using hardware provided.
Note: The large washers are assembled on the top of the oat and
the small washer and nut are assembled against the light xture
retaining band on the bottom.
f. Before tightening, slide the retaining band and bolt as far as they will go
towards the center of the oat.
2. To install light xture into oat with existing light xture retaining band:
a. Position the xtures around the oat.
b. Place the light xture clamp ring under the angle tabs as shown.
c. Slide the light xture in until it snaps into place. The xture may have some
free movement, but should not fall out.
d. Rotate lights to bring the clamp ring stud behind the oat edge.
Figure 1
Figure 2
Figure 3
Figure 4
