ELECTRICAL CONNECTION – 50Hz
Electrical connections must be completed by a licensed electrician or installer in
accordance with European community, national, local codes or ordinances.
CAUTION: Aeration systems require the use of a residual current
device (RCD) with a rated residual operating current not exceeding 30
mA for safe operation. If the proper grounding and RCD are not used,
serial FATAL electrical shock may occur.
ELECTRICAL NOTICE
Supply conductors must be of sufcient cross sectional area to operate the
equipment in regard to cable length, motor nameplate current and voltage ratings. All
cables, conduits and external ducts must enter the enclosure from the bottom only.
Install cables, conduits and external wiring ducts by qualied installer and per local
codes utilizing appropriate bushings and glands. Care must be used to protect cables
when entering and leaving the pond area by the use of protective duct, conduits or
like protection devices. Electrical cable must extend completely onto shore to
power source without breaks or splices. Underwater splices are dangerous
and will void the warranty.
WARNING
DO NOT burn the lighting xtures out of the water except to test
the lamps (60 seconds or less). Light lenses MUST BE completely
covered with water to prevent lens failure.
NOTE: Excessive buildup on the lenses may cause the lenses to
crack, lamps to burn out and gaskets to fail. To maintain maximum
light output and long lamp life, cleaning of the lenses may become
necessary.
DO NOT BYPASS YOUR CONTROL PANEL. (TO DO SO COULD
RESULT IN THE DANGER OF ELECTROCUTION TO ANYONE, HUMAN
OR ANIMAL, IN CONTACT WITH THE WATER IF AN ELECTRICAL
SHORT SHOULD OCCUR.)
1. To wire your unit and main power to your control panel proceed as follows:
A) Electrical cable must extend completely onto shore to power source without
breaks or splices. Underwater splices are dangerous and will void the war
ranty. Securely fasten electrical cables with appropriate devices
B) Connect black lead from the cable to terminal marked 1T1 on terminal strip.
C) Connect white lead from the cable to terminal marked 1T2 on terminal strip.
D) Connect red lead from the cable to terminal marked 1T3 on terminal strip.
E) Connect the green lead to the earthing system terminal.
