Aquatec Fortuna - At the Rear; Completing Assembly; Operation; Control

31
EN
5.5.3 Mounting of height adapter at the
rear
1. Remove the suction cup from the base
plate.
2. Screw the height adapter into the
threaded liner in the base plate.
3. Screw the suction cup onto the height
adapter.
5.5.4 Completing assembly
1. Carefully push together the lifting scis-
sors.
2. Position the seat on the suction cups.
6.1 Control
The AQUATEC FORTUNA is controlled by
means of the hand control device (figure 13).
6.1.1 Lifting
Press the UP button (3, figure 13) at the hand
control (4, figure 13).
The backrest is moved to the upright position
(1, figure 14), and the seat is lifted
(2, figure 14).
Important!
The procedure is the same for the right
and the left suction cup.
Important!
Do not fold the backrest if there is
water in the bath.
Important!
If the battery is empty, the red indicator
light is on (2, figure 13). In this case,
the lift cannot be lowered. Lifting is
however possible. Immediately
recharge the battery.
Important!
P When the button for lifting/lowering
is released, the lift is automatically
stopped.
P If the backrest is folded down, it is
moved to the upright position.
6Operation
