Arad Octave Installation Manual

| 4 |
11.0 Mechanical Data
Maximum Working Pressure
16 bar
Liquid Temperature 0.1 up to 50 º C
Precision Class ISO 4064 rev.2005, Accuracy class 2
Conguration Compact - The display is built in to the unit
Power Source 2 D size Li-battery: up to 15 years life time
Environmental Protection IP 68, Ambient operation temp. -25°C up to +55°C
Volume Display Options
1. Net (Forward less reverse)
2. Forward only
3. Reverse only
4. Forward & reverse alternating
Data Logger
Volumes and alarms data (48KB)
Connections
1½-2” threaded: with couplings to NPT/ BSP
2”-12” anged: anges according to ISO, BS 10 and ANSI 150
Severity levels
Mechanical class M1
Electromagnetic environment class E1
Pressure Loss
ΔP 0.16 bar
Outputs
Analog Output
The Analog Output shows the currently measured ow rate.
The Analog Output is a 4 - 20 mA current loop (the end user must supply power to
the unit).
The Analog Output is programmable for forward and reverse ow (see Operation
Manual for more details).
The 20mA point is programmable per customer request (To any ow lower than the
max ow of the meter).
Digital (pulse) Output
The Digital (pulse) Output is an open drain transistor output that provides pulse per
quantity with these options:
1. Two scaled forward, reverse or net mode pulses
2. One scaled forward, reverse or net mode pulse and one alarm frequency output
3. Measuring units of the output can be programmed dierent than displayed units
Pulse resolution will be shown on the display for each pulse separately
Dry Contact Output
The Dry Contact Output is a dual relay output that provides pulse per quantity with
these options:
1. Two scaled forward, reverse or net mode pulses
2. Measuring units of the output can be programmed dierent than displayed units
Pulse resolution will be shown on the display for each pulse separately
Onsite power supply of 12-24 VDC is needed.
Encoder Output
The Encoder Output is a serial communication collector utilizing UI1203 or UI1204
communication protocol. (Sensus protocol) Pulse output included.
Modbus Protocol Output
The Modbus Protocol Output has the following available functions:
1. Alarms (battery, empty pipe)
2. AMR serial number
3. Real Time Clock (RTC)
4. Volume units
5. Flow rate units
6. Current ow
7. Flow direction
8. Forward and reverse volumes
9. Flow and volume resolution
Output Extension Cable
5m extension cable for installation in pits and vaults

Arad Octave Specifications

General

Protection Class	IP68
Type	Ultrasonic flow meter
Communication	M-Bus
Pressure Rating	16 bar
Power Source	Internal battery
