9
CONTINUES
 
For the harness connection please refer to the labels on the cables (Fig. 2):
Cable marking Connection
2 ÷ 6
Relative section valve
P
Proportional valve
G
Main valve
L / R
Adjustable actuators / Guard actuators
 
Connect to valve unit by means of the cables for section control (sold separately - Ref. ARAG
General Catalogue).
• Open connector A slide (1, Fig. 2).
• To position connector, insert it inside socket then press: 

• Close slide (2, Fig. 2) until it locks in place.
Assemble the connector B


Fig.






󰀨


󰀨

4 USE






