Aragon 8008 - Technical Specifications

16
8 0 0 8 A N D I R I D I U M U S E R G U I D E
©2012 Indy Audio Labs, LLC all rights reserved / Revision20130220
Document No. 1000571
technical specifications
specification Iridium 8008
Power output
400W into 8Ω
600W into 4Ω
200W into 8Ω
400W into 4Ω
THD
<0.02% (8Ω)
<0.03% (4Ω)
<0.015% (both channels driven, 8Ω)
<0.03% (both channels driven, 4Ω)
Frequency response
5Hz to 20kHz +0/-0.1dB
5Hz to 100kHz +0/-2 dB
5Hz to 20kHz +0/-0.1 dB
5Hz to 100kHz +0/-1.2 dB
Voltage Gain
28dB 28dB
Tim/dim distortion
0.01% 0.003%
Phase Inversion
No No
S/N
>112 dB, A-weighted >110 dB, A-weighted
Slew Rate
> 240 V/μSec >120 V/uSec
Damping factor
200, 8Ω @50Hz 400, 8Ω @50Hz
Input sensitivity
1W: 60mV (SE & balanced)
400W: 1.2V (SE & balanced)
1W: 120mV (SE & balanced)
200W: 1.7V (SE & balanced)
Input impedance
15kΩ (SE)
45kΩ (bal)
46kΩ (SE)
70kΩ (Balanced)
Rail voltage
+/- 50Vdc +/- 70Vdc
Power consumption
standby: <1W
idle: 120W
max: 1500W
standby: <1W
idle: 120W
max: 1500W
ethernet/RS-232
status & control of standby/on status & control of standby/on, channel configuration
12 Volt Trigger
standby/on control standby/on control
inputs
gold-plated, panel-mounted RCA jacks
XLR balanced jack
gold-plated, panel-mounted RCA jacks
XLR balanced jack
outputs
2 sets gold-plated, 60-Amp insulated speaker
binding posts
2 sets gold-plated, 60-Amp insulated speaker
binding posts
Unit dimensions
7”(17.8 cm) H x 16”(40.6 cm) D x 19”(48.3 cm) W 7”(17.8 cm) x 16”(40.6 cm) x 19”(48.3 cm)
Unit weight
60 lbs (27.2kg) 63 lbs. (28.6 kg)
Finish
black or silver w/ satin anodized finish black or silver w/ satin anodized finish
Shipping carton
12”(30.5 cm) x 22”(55.9 cm) x 24”(61 cm) 12”(30.5 cm) x 22”(55.9 cm) x 24”(61 cm)
Carton weight
68 lbs (30.8kg) 71 lbs. (32.2 kg)
