18
English
TO INSTALL / REMOVE CHIN COVER
To install, unclip front part of the cheek pad ①. Pull airflow spoiler down ②
and insert the frame of the chin cover between the shell and spoiler, centering
the cover on the helmet ③. Further press the 2 tabs on the frame until they
click and lock in place ④. Hook the chin cover end tab on the neckroll frame
⑤, reposition the neckroll end tab and replace the cheek pad ⑥. Repeat for
the other side.
To remove, unclip front part of the cheek pad ⑦ and unhook the chin cover
end tab from the neckroll frame ⑧. Repeat for the other side. Grasp center
of the chin cover and rotate it to the left by 3 – 4 cm (1-1/4” - 1-1/2”) ⑨ and
remove it from the helmet. Replace the cheek pad
10
.
TO REMOVE/REPLACE COMFORT LINING
The comfort lining is secured to the helmet by plastic bosses ①.
To remove the lining, undo bosses by grasping the lining as close to each
boss as possible ② and pulling straight up ③. Note the fore & back, top &
bottom sides of the lining for replacement.
NOTE: The lining is equipped with a 5mm surface foam layer. The layer is
removable to offer a bit more room if desired. Gently remove it from the
pad. Once removed this foam layer will not reattache securely ④.
To wash the comfort lining, put it into lukewarm water with small amount of
laundry soap or your own shampoo and wash gently by hand. Rinse well with fresh
water and wipe off with a soft cloth. Dry it in the shade at ambient temperature.
② ③
④
