ARB CKMTA12 - 6 Parts List

6 Parts List
24
CKMTA12 & CKMTA24
Air Compressor
Specs:
ITEM #
QTY
DESCRIPTION
PART #
NOTES
01(a)
2
COMPRESSOR ASSEMBLY (12V)
CKM01
1
Voltage
12 Volts (CKMTA12), 24 Volts (CKMTA24)
01(b)
2
COMPRESSOR ASSEMBLY (24V)
CKM02
1
Current Draw
No-Load
28A (CKMTA12 only)
02
1
TWIN COMPRESSOR MOUNT ASSEMBLY
320108
Load
50A (CKMTA12 only)
03
3
O-RING (BS031N70)
160241
2
Air Flow
174.3L/min @ 0Bar [6.16CFM @ 0psi]
04
1
COUPLER MANIFOLD
320227
131.7L/min @ 2Bar [4.65CFM @ 29psi]
05
2
FLAT WASHER (M6)
6151046
Total Weight
8.8kg [19.4lbs]
06
2
MANIFOLD BOLT (M6 x 60mm)
200716
Size
102mm x 190mm x 275mm (H,L,W)
07
2
O-RING (METRIC 6 x 2 N70)
160242
[4.0” x 7.5” x 10.8”]
08
1
MANIFOLD CAP
320214
Outlet Port
1
/
4
” NPT
09
1
PRESSURE SWITCH (1/4” NPT)
180901
Pressure Switch
Open
10.3Bar [150psi]
10
8
HEX BOLT (M6 x 12mm)
200702
Pressure Switch
Closed
9.3Bar [135psi]
11
1
COVER ASSEMBLY, CKMT
320110
Safety Valve
OPEN @ > ~12.4 [180 PSI]
12
2
O-RING (BS029N70)
160250
2
13
2
AIR FILTER FLANGE (1/4” NPT)
320212
14
2
AIR FILTER COVER
320501A
3
Notes:
15
2
AIR FILTER ELEMENT (DISK TYPE)
290503
3
16
2
AIR FILTER BASE
320501B
3
*
4
HEX BOLT (M6 X 20mm)
6151213
*
4
FLAT WASHER (M6)
200709
1
Motor voltage is the only difference between
*
4
SPRING WASHER (M6)
4581287
The CKMAT12 and CKMTA24 compressors.
*
1
WIRING LOOM SUPPLY (CKMTA12 /24)
180414
4
CKM motors are serviceable. Contact ARB.
*
1
WIRING LOOM SWITCH (CKMTA12 / 24)
180415
4
*
1
RELAY, SEALED (12V,40A)
180905
2
Complete set of O-ring seals is also available
*
1
SWITCH|COMPRESSOR
180222
as O-ring Service Kit #320301.
*
2
FUSE,40A,MAXI TYPE
180703
*
1
MINI BLADE FUSE HOLDER, 5A FUSE
180418
5
3
AIR FILTER COVER (14) & BASE (16) available
*
1
EYE TERMINAL,8MM (RED)
180707
5
only in AIR FILTER ASSY #320501 which also
*
1
CABLE JOINER, INSULATED (RED)
180708
5
includes the element.
*
1
INSTALLATION GUIDE,CKMA
2102MTA12
4
Wiring looms set of #180414 & #180415 suits both
12 & 24 volt systems. See full wiring diagram attached.
5
Only included in the CKMAT24
#
Available separately or included with Air Locker kits.
*
Not illustrated in exploded view.
