Arbor Technology MB-i77Q0 - Specifications

- 2 -
Specications
Form Factor Micro-ATX Industrial Motherboard
CPU 3rd generation Intel
®
Core™ i7/i5/i3 processors in LGA1155 socket
Chipset Intel
®
PCH Q77
System Memory
4 x 240-pin DDR3 DIMM sockets, supporting 1333/1600MHz SDRAM
up to 32GB
Display
Integrated Intel
®
HD Graphics 4000 and HD Graphics 2500
• 1 x DVI-I connector, supporting either analog RGB or DVI, resolution
up to 2048 x 1536 for analog RGB and 1920 x 1200 for TMDS
• 1 x DVI-D connector, supporting resolution up to 1920 x 1200
• Dual Channel 24-bit LVDS up to 1600 x 1200 resolution supported
Ethernet
1 x Intel
®
82583V Gigabit Ethernet Controller
1 x Intel
®
82579LM Gigabit Ethernet PHY w/ iAMT
I/O Chip Fintek F71869ED + Fintek F81216AD
BIOS AMI BIOS
Watchdog Timer 1~255 levels reset
Serial ATA
4 x Serial ATA with 300MB/s HDD transfer rate
2 x Serial ATA with 600MB/s HDD transfer rate
Intel
®
Rapid Storage Technology supported
RAID 0,1,5,10 supported
Serial Port
4 x COM ports: COM1~3 RS-232, COM4 RS-232/422/485 selectable
w/ auto-ow control
Universal Serial Bus 4 x USB 3.0/2.0 compatible ports, 10 x USB 2.0 ports
KBMS
1 x 6-pin wafer connector for PS/2 keyboard and mouse
Expansion Bus
1 x PCIe x16 slot
1 x PCIe x1 slot
1 x PCIe x4 interface in x8 slot
1 x PCI slot
Digital I/O 1 x 16-bit digital I/O, 8 in/8 out
Audio Realtek ALC886 HD Audio Codec, Mic-in/Line-in/Line-out
Power Consumption
6.5A@+12V, 3.8A@+5V, 1.8A@+3.3V with Intel
®
Core™ i7-3770
3.4GHz processor (Typical)
Power Connector 24-pin + 4-pin ATX connector
Certication CE/FCC Class B
Operating Temp. 0ºC ~ 60ºC (32ºF ~ 140ºF)
Storage Temp. -20ºC ~ 80ºC (-4ºF ~ 176ºF)
Humidity 0% ~ 95% non-condensing
Dimension (L x W) 244 x 244 mm (9.6” x 9.6”)
