Jumper / Connector Quick Reference
Connectors
Label Description
ATX12V1 ATX +12V connector
FAN1~3 Fan power connectors
ATX1 ATX power connector
SATA1~6 Serial ATA connectors
JFRT1 Switches and indicators
COM1~3 Serial port connectors
COM4 RS-232/422/485 connector
AUDIO1 Audio interface port
AUDIO3 AUX audio connector
LAN1~2 RJ-45+USB stacked connectors
USB1~3 USB connectors
DVI2 DVI-I & DVI-D
KBMUSB1
PS/2 keyboard and USB stacked
connector
JDIO1 Digital I/O connector
LVDS1 LCD connector
LVDSBL1 LCD inverter connector
J80P1 I/O 80 port
Jumpers
Label Description
JBIOS1 BIOS update port
JP2 CMOS setup
JP8 Congures LVDS features
JP9 Congures LVDS features
JP10 Congures LVDS features
JP11 Congures LVDS features
JP12 Congures Intel
®
ME mode
JP14 Enables/disables LVDS
JRS2
Congures COM4 RS-232, 422,
485
JKBMS1 Congures KB/MS power source
JLVDS1 Congures LCD voltage
