ARC 200 - Page 24

21
No.
Item
Stock no.of 200
Qty
Remarks
1
Plastic shell front panel
262005-00275
1
2
Crossbeam 1
766007-00109
1
3
Upper board assembly
220425-00008
1
4
Drive board assembly
210310-00014
1
5
Upper isolation board
775007-00203
1
6
Plastic shell rear panel
262011-00140
1
7
Fan protective cover
746001-00040
1
8
Plastic vertical beam(long)
776025-00002
2
9
Plastic vertical beam(short)
776025-00001
2
10
Crossbeam 2
766007-00110
1
11
Radiator wind deflector
766003-00279
2
12
Right radiator
264005-00103
1
13
MOSFET tube
735002-00013
12
14
Press pieces
766003-00354
12
15
Diode
730001-00005
12
16
Rectifier bridge
735004-00002
2
17
Left radiator
264005-00102
1
18
Middle board assembly
210570-00005
1
19
Bottom board assembly
210070-00007
1
20
Rack assembly
210200-00005
1
21
Flat washer ф4
779007-00017
12
22
Spring washer ф4
779007-00006
12
23
Gb_cross_screws_type1
m4x16
779002-00027
12
Table4-9-1: Main components list-200
Note: This table is for reference only, and the detail of actual product shall prevail. If no
special remarks, the input voltage mentioned in above table is three phase.
