ALPHA 7/8/9 CD SERVICE MANUALALPHA 7/8/9 CD SERVICE MANUAL
Z13 IC HCMOS SM 74HCU04 5K7404
Z14 IC DIGITAL FILT SM5843APT 5G5843
Z16 IC VREG POS LM317T 5D317T
Z17 IC VREG POS LM337T 5D337
Z18 IC AUDIO DUAL SM 4560D 5B4560M
Alpha 7/8/9 CD Non PCB Parts, Metalwork etc.
Part No. Description
B3002 BATTERY AA
B2009 CDM14 MECHANISM
E802CH CHASSIS
E802CP ALPHA 7/8/9 CD/TUNER COVERPLATE
E802MI PCB INSULATOR
E806RP REAR PANEL
E810FP ALPHA 7/8 TUNER FASCIA
E813PM CD DRAWER FRONT
E815PM POWER BUTTON
E822PM FOOT
E823PM ALPHA 7 BADGE
E824PM ALPHA 8 BADGE
E825PM ALPHA 9 BADGE
HP006 SNAP RIVET (HOLDS MECH IN PLACE)
L801RC CR14 REMOTE CONTROL HANSET
L807CA FLEX FOILS MAIN BOARD TO DAC PCB
SH054 OWNERS HANDBOOK
SH058 WARRANTY LEAFLET
