ALPHA 7/8/9 CD SERVICE MANUALALPHA 7/8/9 CD SERVICE MANUAL
R11 RESISTOR SM W4 2K2 2% 1A222
R12 RESISTOR SM W4 2K2 2% 1A222
R13 RESISTOR SM W4 2K2 2% 1A222
R14 RESISTOR SM W4 2K2 2% 1A222
R15 RESISTOR SM W4 2K2 2% 1A222
R16 RESISTOR SM W4 2K2 2% 1A222
R17 RES MF FU W3 10R 5% NFR25 1G010
R18 RESISTOR SM W4 10R 2% 1A010
R19 RESISTOR SM W4 47K 2% 1A347
R20 RESISTOR SM W4 47K 2% 1A347
R21 RES MF FU W3 100R 5% NFR25 1G110
R25 RESISTOR SM W4 0R0 2% 1A000
R34 RESISTOR SM W4 0R0 2% 1A000
R35 RESISTOR SM W4 100R 2% 1A110
R36 RESISTOR SM W4 100R 2% 1A110
R37 RESISTOR SM W4 100R 2% 1A110
R38 RESISTOR SM W4 100R 2% 1A110
R39 RESISTOR SM W4 220R 2% 1A122
R40 RESISTOR SM W4 100R 2% 1A110
R41 RESISTOR SM W4 220R 2% 1A122
R42 RESISTOR SM W4 0R0 2% 1A000
R43 RESISTOR SM W4 100R 2% 1A110
R44 RESISTOR SM W4 100R 2% 1A110
R45 RES MF W4 1K2 1% 1H212
R46 RES MF W4 1K2 1% 1H212
R47 RES MF W4 1K2 1% 1H212
R48 RES MF W4 1K2 1% 1H212
R49 RES MF W4 3K3 1% 1H233
R50 RES MF W4 3K3 1% 1H233
R51 RES MF W4 3K3 1% 1H233
R52 RES MF W4 3K3 1% 1H233
R53 RESISTOR SM W4 1K0 2% 1A210
R54 RESISTOR SM W4 1K0 2% 1A210
R55 RESISTOR SM W4 4K7 2% 1A247
R56 RESISTOR SM W4 11K 2% 1A311
R57 RESISTOR SM W4 11K 2% 1A311
R58 RESISTOR SM W4 18K 2% 1A318
R59 RESISTOR SM W4 18K 2% 1A318
R64 RESISTOR SM W4 47R 2% 1A047
R65 RESISTOR SM W4 47R 2% 1A047
R66 RESISTOR SM W4 100K 2% 1A410
R67 RESISTOR SM W4 470R 2% 1A147
R68 RESISTOR SM W4 10K 2% 1A310
R69 RESISTOR SM W4 10K 2% 1A310
R72 RESISTOR SM W4 100R 2% 1A110
R73 RESISTOR SM W4 100R 2% 1A110
R74 RESISTOR SM W4 100R 2% 1A110
R75 RESISTOR SM W4 100R 2% 1A110
R80 RESISTOR SM W4 2K2 2% 1A222
R81 RESISTOR SM W4 2K2 2% 1A222
R82 RESISTOR SM W4 680K 2% 1A468
R84 RESISTOR SM W4 680K 2% 1A468
R85 RESISTOR SM W4 680K 2% 1A468
R86 RESISTOR SM W4 0R0 2% 1A000
R91 RESISTOR SM W4 0R0 2% 1A000
R92 RESISTOR SM W4 0R0 2% 1A000
R94 RESISTOR SM W4 220R 2% 1A122
R95 RESISTOR SM W4 220R 2% 1A122
R96 RESISTOR SM W4 2K4 2% 1A224
R97 RESISTOR SM W4 2K4 2% 1A224
R98 RESISTOR SM W4 0R0 2% 1A000
R99 RESISTOR SM W4 0R0 2% 1A000
R102 RESISTOR SM W4 0R0 2% 1A000
R103 RESISTOR SM W4 0R0 2% 1A000
R104 RES MF W4 1K2 1% 1H212
R108 RESISTOR SM W4 100K 2% 1A410
R109 RESISTOR SM W4 100K 2% 1A410
R110 RESISTOR SM W4 100K 2% 1A410
R111 RESISTOR SM W4 100K 2% 1A410
R112 RESISTOR SM W4 680K 2% 1A468
R113 RESISTOR SM W4 680K 2% 1A468
R114 RESISTOR SM W4 100K 2% 1A410
R115 RESISTOR SM W4 0R0 2% 1A000
R117 RESISTOR SM W4 0R0 2% 1A000
RLY1 RELAY 960 OHM 51SB12T A205
SH1 PHONO EMC SHIELD E808MC
SK1 PHONO SKT 4-WAY EMC GOLD 8D225
SK203 32-WAY FFC CONN VERT 8K8032
SK204 23-WAY FFC CONN VERT 8K8023
X1 CRYSTAL 16.9344MHz PARALLEL 7X012
X1 GROMMET 8 I/D X 6.5 THK F021
Z1 IC OPAMP SM OP27 5B027S
Z2 IC OPAMP SM OP27 5B027S
Z3 IC AUDIO DUAL SM 4560D 5B4560M
Z4 IC AUDIO DUAL SM 4560D 5B4560M
Z5 IC VREG POS 78L05 5D78L05
Z7 IC HCMOS SM 74HC74 5K7474
Z8 IC HCMOS SM 74HC74 5K7474
Z11 IC VREG POS 78L05 5D78L05
Z12 IC CMOS SDECO DAC SM5864AP 5G5864
