Arcam Alpha 8 User Manual

ALPHA 7/8/9 CD SERVICE MANUALALPHA 7/8/9 CD SERVICE MANUAL
Alpha 8 DAC PCB Only Parts List
Ref. No. Description Part No.
C1 PPRO 2N7 63V 5% RA 2D227
C2 PPRO 2N7 63V 5% RA 2D227
C3 PPRO 2N7 63V 5% RA 2D227
C4 PPRO 2N7 63V 5% RA 2D227
C5 PPRO 2N7 63V 5% RA 2D227
C6 PPRO 2N7 63V 5% RA 2D227
C7 PPRO 1N0 63V 5% RA 2D210
C8 PPRO 1N0 63V 5% RA 2D210
C9 PPRO 1N0 63V 5% RA 2D210
C10 PPRO 1N0 63V 5% RA 2D210
C11 PPRO 1N0 63V 5% RA 2D210
C12 PPRO 1N0 63V 5% RA 2D210
C13 PPRO 470P 63V 5% RA 2D147N
C14 PPRO 470P 63V 5% RA 2D147N
C15 PPRO 470P 63V 5% RA 2D147N
C16 PPRO 470P 63V 5% RA 2D147N
C17 MLC 100P 100V NPO 5% SM 2C110
C18 ELST 10U 50V 2N610
C19 ELST 10U 50V 2N610
C20 PPRO 1N3 63V 5% RA 2D213N
C21 ELST 10U 50V 2N610
C22 PCRB 100N 100V 5% RA 5mm 2H410
C23 ELST 10U 50V 2N610
C24 ELST NON POLAR 10UF 35V 2U610
C25 ELST NON POLAR 10UF 35V 2U610
C26 PPRO 4N7 63V 5% RA 2D247N
C27 PCRB 100N 100V 5% RA 5mm 2H410
C29 ELST 10U 50V 2N610
C30 PPRO 4N7 63V 5% RA 2D247N
C34 MLC 10N 50V X7R 10% SM 2C310
C35 MLC 470P 100V NPO 5% SM 2C147
C36 MLC 470P 100V NPO 5% SM 2C147
C37 MLC 10N 50V X7R 10% SM 2C310
C38 MLC 10N 50V X7R 10% SM 2C310
C39 MLC 10N 50V X7R 10% SM 2C310
C40 MLC 10N 50V X7R 10% SM 2C310
C41 MLC 10N 50V X7R 10% SM 2C310
C42 PPRO 470P 63V 5% RA 2D147N
C43 PPRO 470P 63V 5% RA 2D147N
C44 PPRO 470P 63V 5% RA 2D147N
C45 PPRO 470P 63V 5% RA 2D147N
C46 MLC 100P 100V NPO 5% SM 2C110
C47 MLC 47P 100V NPO 5% SM 2C047
Alpha 8 DAC PCB Only Parts List
Ref. No. Description Part No.
C49 ELST 22U 20V OSCON 2P622
C50 ELST 22U 20V OSCON 2P622
C53 ELST 220U 16V 2N722
C55 MLC 100N 50V X7R 10% SM 2C410
C56 ELST 100U 25V 2N710
C57 ELST 100U 25V 2N710
C58 ELST NON POLAR 10UF 35V 2U610
C59 ELST NON POLAR 10UF 35V 2U610
C60 PPRO 4N7 63V 5% RA 2D247N
C61 PPRO 4N7 63V 5% RA 2D247N
C62 MLC 10N 50V X7R 10% SM 2C310
C63 ELST 470U 25V RA 2N747
C64 ELST 470U 25V RA 2N747
C65 MLC 10N 50V X7R 10% SM 2C310
C66 ELST NON POLAR 2.2UF 50V 2V522
C67 ELST NON POLAR 2.2UF 50V 2V522
C68 MLC 10N 50V X7R 10% SM 2C310
C69 MLC 33P 100V NPO 5% SM 2C033
D1 SSDIODE 1N4148 75V 3A4148
D2 SSDIODE 1N4148 75V 3A4148
L1 33UH IND SM 1812 180mA 7B033
L2 33UH IND SM 1812 180mA 7B033
L3 33UH IND SM 1812 180mA 7B033
L4 33UH IND SM 1812 180mA 7B033
L5 33UH IND SM 1812 180mA 7B033
L6 2U2H INDUCTOR 7D922
Q1 TRANS LF SS N SM BC847B 4A847
Q3 TRANS LF SS N SM BC847B 4A847
Q5 TRANS LF SS N SM BC847B 4A847
Q6 TRANS LF SS N SM BC847B 4A847
Q8 TRANS LF SS N SM BC847B 4A847
Q9 TRANS LF SS N SM BC847B 4A847
Q11 TRANS MOSFET SW ZVNL120A 4K120
R1 RESISTOR SM W4 1K0 2% 1A210
R2 RESISTOR SM W4 1K0 2% 1A210
R3 RESISTOR SM W4 1K0 2% 1A210
R4 RESISTOR SM W4 1K0 2% 1A210
R5 RESISTOR SM W4 1K0 2% 1A210
R6 RESISTOR SM W4 1K0 2% 1A210
R7 RESISTOR SM W4 1K0 2% 1A210
R8 RESISTOR SM W4 1K0 2% 1A210
R9 RESISTOR SM W4 2K2 2% 1A222
R10 RESISTOR SM W4 2K2 2% 1A222
