ALPHA 7/8/9 CD SERVICE MANUALALPHA 7/8/9 CD SERVICE MANUAL
R59 RES MF W4 330R 1% 1H133
R60 RES MF W4 1% 8K2 1H282
R61 RES MF W4 1% 8K2 1H282
R62 RES MF W4 330R 1% 1H133
R63 RES MF W4 1% 33K 1H333
R64 RES MF FU W3 5% 10R NFR25 1G010
R102 RES MF W4 3K9 1% 1H239
R103 RES MF W4 3K9 1% 1H239
R104 RES MF W4 3K9 1% 1H239
R105 RES MF W4 1% 10K 1H310
R106 RES MF W4 1% 10K 1H310
R107 RES MF W4 1% 33K 1H333
R108 RES MF W4 3K9 1% 1H239
R109 RES MF W4 3K9 1% 1H239
R110 RES MF W4 22K 1% 1H322
R111 RES MF W4 120R 1% 1H112
R112 RES MF W4 22R 1% 1H022
R113 RES MF W4 1% 10K 1H310
R291 RES MF FU W3 5% 3R3 NFR25 1G833
R292 RES MF W4 1% 8K2 1H282
R293 RES MF W4 1% 8K2 1H282
R294 RES MF W4 1% 1K0 1H210
R295 RES MF W4 1% 10K 1H310
R296 RES MF W4 1% 10K 1H310
R297 RES MF W4 1% 10K 1H310
R298 RES MF W4 1% 10K 1H310
R301 RES MF W4 1% 33K 1H333
R302 RES MF W4 1% 12K 1H312
R303 RES MF W4 1% 5K6 1H256
R304 RES MF W4 1% 3K3 1H233
R305 RES MF W4 1% 2K2 1H222
R306 RES MF W4 1% 1K5 1H215
R307 RES MF W4 1% 1K2 1H212
R308 RES MF W4 1% 8K2 1H282
R309 RES MF W4 1% 3K3 1H233
R310 RES MF W4 1% 2K2 1H222
R311 RES MF W4 1% 1K5 1H215
R312 RES MF W4 1% 1K2 1H212
R313 RES MF W4 1% 8K2 1H282
R314 RES MF W4 1% 220R 1H122
RX201 REMOTE CONTROL RX SBX1610-62 38KHZ B2103
SH1 PHONO EMC SHIELD E808MC
SK1 IEC MAINS 2-PIN PCB 8A014
SK2 8+8 WAY FEMALE HORIZ SKT 8K6416
SK4 PHONO SKT 2-WAY HOR EMC 8D222
SK5 PHONO SKT SINGLE EMC 8D220
SK201 23-WAY FFC CONN VERT 8K8023
SK203 32-WAY FFC CONN VERT 8K8032
SK204 23-WAY FFC CONN VERT 8K8023
SK205 5-WAY AMP CT CONN 8K2005
SK291 32-WAY FFC CONN VERT 8K8032
SK301 32-WAY FFC CONN HORIZ 8K8132
SW201 SW PUSH 4PCO A1014
SW301 TACT SWITCH 2-PIN LOW PROF A1504
SW302 TACT SWITCH 2-PIN LOW PROF A1504
SW303 TACT SWITCH 2-PIN LOW PROF A1504
SW304 TACT SWITCH 2-PIN LOW PROF A1504
SW305 TACT SWITCH 2-PIN LOW PROF A1504
SW306 TACT SWITCH 2-PIN LOW PROF A1504
SW307 TACT SWITCH 2-PIN LOW PROF A1504
SW308 TACT SWITCH 2-PIN LOW PROF A1504
SW309 TACT SWITCH 2-PIN LOW PROF A1504
SW310 TACT SWITCH 2-PIN LOW PROF A1504
SW311 TACT SWITCH 2-PIN LOW PROF A1504
SW312 TACT SWITCH 2-PIN LOW PROF A1504
T201 ALPHA 7 CD MAINS TRANSFORMER L811TX
T202 DIGITAL OUTPUT COUPLER K 7E015
X1 CRYSTAL 16.9344MHz PARALLEL 7X012
X201 CER RESON 4.00MHz 7W005
Z1 IC OPAMP DUAL NJM2114D 5B2114
Z101 IC OPAMP DUAL NJM2114D 5B2114
Z201 IC CD DAC PCM1710U 5G1710
Z202 IC HCMOS 74HCU04 5J7404
Z203 IC VREG POS 78L05 5D78L05
Z204 IC VREG POS LM317T 5D317T
Z205 IC VREG POS LM337T 5D337
Z206 IC VREG POS LM317T 5D317T
Z207 IC VREG POS LM317T 5D317T
Z208 IC VREG POS 7805 5D7805
Z209 IC VREG NEG 7915 5D7915
Z210 IC MOTOR DRIVER LB1641 5Q1641
Z211 IC CMOS MICRO PIC16C54XT/P 5H16C54X
Z211 IC SOCKET 18 PIN 0.3'' 8S018
Z212 IC CD CXP826P16Q MICRO 5G826
