H / P P S E MANALPHA ONE/7R/8R/8P AMPLIFIER SERVICE MANUAL
4
C29 ELST 1U0 50V 20% RA 2N510 8R
C30 ELST 22U 63V ELECT 2N622 7R
C30 ELLL 47U 10V ELECT 2R647 A1
C30 ELEC 10U 25V CERAFINE 2P610CC 8R
C101 ELST 100U 100V 2N710B 7R
C102 PEST 47N 63V 10% 2K347 7R
C103 PCRB 100N 100V 5% RA
5mm
2H410 7R
C104 PEST 47N 63V 10% 2K347 7R
C105 PSTY 33P 160V ENCAP
1PF%
2F033 7R
C107 PPRO 4N7 63V 5% RA 2D247N 7R
C108 PPRO 100P 63V 5% RA 2D110N 7R
C109 ELST 100U 25V 2N710 A1
C110 ELST 22U 20V OSCON 2P622 7R
C110 ELST 22U 63V ELECT 2N622 A1
C111 ELST 100U 100V 2N710B 7R
C112 ELST 100U 100V 2N710B 7R
C113 PEST 15N 63V 10% 2K315 7R
C114 PEST 15N 63V 10% 2K315 7R
C116 ELST 100U 25V 2N710 7R
C117 CERD 470P 63V 20% RA 2A147 7R
C118 CERD 1N0 63V 20% RA 2A210 7R
C119 ELST 1U0 50V 20% RA 2N510 7R
C120 CERD 470P 63V 20% RA 2A147 7R
C121 ELST 1U0 50V 20% RA 2N510 7R
C122 ELST 100U 25V 2N710 7R
C123 ELST 100U 25V 2N710 7R
C124 PPRO 4N7 63V 5% RA 2D247N 7R
C125 PCRB 100N 100V 5% RA
5mm
2H410 7R
C126 PCRB 100N 100V 5% RA
5mm
2H410 7R
C127 ELST 220U 16V 2N722 7R
C128 PCRB 100N 100V 5% RA
5mm
2H410 7R
C130 ELST 22U 63V ELECT 2N622 7R
C130 ELLL 47U 10V ELECT 2R647 A1
C130 ELEC 10U 25V CERAFINE 2P610CC 8R
C200 CERD 1N0 63V 20% RA 2A210 7R
C201 SUPPR CAP 4N7 250V 2K247 7R
C204 ELST 10m 50V RA 32mm 2N910 7R
C204 ELST 6M8 35V RA 2N868 A1
C205 ELST 10m 50V RA 32mm 2N910 7R
C205 ELST 6M8 35V RA 2N868 A1
C206 PCRB 100N 100V 5% RA
5mm
2H410 7R
C207 PCRB 100N 100V 5% RA
5mm
2H410 7R
C208 PPRO 4N7 63V 5% RA 2D247N 7R
C209 PPRO 4N7 63V 5% RA 2D247N 7R
C210 ELST 10U 50V 2N610 7R
C211 ELST 10U 50V 2N610 7R
C212 CERD 10N 63V 20% RA 2A310 7R
C213 CERD 10N 63V 20% RA 2A310 7R
C214 CERD 10N 63V 20% RA 2A310 7R
C215 CERD 10N 63V 20% RA 2A310 7R
C216 CERD 10N 63V 20% RA 2A310 7R
C217 CERD 10N 63V 20% RA 2A310 7R
C301 CERD 10N 63V 20% RA 2A310 7R
C302 CERD 10N 63V 20% RA 2A310 7R
C502 PCRB 100N 100V 5% RA
5mm
2H410 A1
C303 CERD 1N0 63V 20% RA 2A210 7R
C304 CERD 1N0 63V 20% RA 2A210 7R
C305 CERD 47P 63V -20% +80%
RA
2A047 7R
C306 CERD 47P 63V -20% +80%
RA
2A047 7R
C401 ELST 10U 50V 2N610 7R
C402 PEST 220N 63V 10% 2K422 7R
C402 PCRB 100N 100V 5% RA
5mm
2H410 A1
C403 PCRB 100N 100V 5% RA
5mm
2H410 A1
C403 PEST 220N 63V 10% 2K422 7R
C404 PPRO 4N7 63V 5% RA 2D247N 7R
C404 2N2 PP 2D222 A1
C405 ELST 10U 50V 2N610 7R
C406 CERD 100P 63V 20% RA 2A110 7R
C407 CERD 100P 63V 20% RA 2A110 7R
C408 CERD 10P 63V 20% RA 2A010 7R
C501 ELST 10U 50V 2N610 7R
C502 PEST 220N 63V 10% 2K422 7R
C503 PEST 220N 63V 10% 2K422 7R
C503 PCRB 100N 100V 5% RA
5mm
2H410 A1
C504 PPRO 4N7 63V 5% RA 2D247N 7R
C504 2N2 PP 2D222 A1
C505 ELST 10U 50V 2N610 7R
