H / P P S E MANALPHA ONE/7R/8R/8P AMPLIFIER SERVICE MANUAL
5
C506 CERD 100P 63V 20% RA 2A110 7R
C507 CERD 100P 63V 20% RA 2A110 7R
C508 CERD 10P 63V 20% RA 2A010 7R
C601 PPRO 100P 63V 5% RA 2D110N 7R
C602 CERD 47P 63V 20% RA 2A047 7R
C603 ELST 22U 63V 2N622 7R
C604 PPRO 4N7 63V 5% RA 2D247N 7R
C605 PPRO 1N3 63V 5% RA 2D213N 7R
C606 ELST 10U 50V 2N610 7R
C701 PPRO 100P 63V 5% RA 2D110N 7R
C702 CERD 47P 63V 20% RA 2A047 7R
C703 ELST 22U 63V 2N622 7R
C704 PPRO 4N7 63V 5% RA 2D247N 7R
C705 PPRO 1N3 63V 5% RA 2D213N 7R
C706 ELST 10U 50V 2N610 7R
C801 PPRO 100P 63V 5% RA 2D110N 7R
C802 PPRO 100P 63V 5% RA 2D110N 7R
C803 ELST 10U 50V 2N610 7R
C804 ELST 10U 50V 2N610 7R
C805 CERD 10N 63V 20% RA 2A310 7R
C806 CERD 10N 63V 20% RA 2A310 7R
C901 CERD 10N 63V 20% RA 2A310 7R
C902 ELST 220U 16V 2N722 7R
C903 CERD 10N 63V 20% RA 2A310 7R
C904 CERD 10N 63V 20% RA 2A310 7R
C905 CERD 10N 63V 20% RA 2A310 7R
C906 CERD 10N 63V 20% RA 2A310 7R
C907 ELST 1M0 25V 2N810 7R
C1000 CERD 10N 63V 20% RA 2A310 7R
CL1 ALPHA AMP 7/8 HEATS NK
CLAMP
E82201 7R
CL2 ALPHA AMP 7/8 HEATS NK
CLAMP
E82201 7R
D1 RECT FIER 1N4003F 1A
200V
3B4003 7R
D2 ZENER 10V 400MW 3C11004 7R
D3 ZENER 10V 400MW 3C11004 7R
D4 ZENER 10V 400MW 3C11004 7R
D5 SSDIODE 1N4148 75V 3A4148 7R
D6 RECT FIER 1N4003F 1A
200V
3B4003 8R
D7 SSDIODE 1N4148 75V 3A4148 7R
D8 RECT FIER 1N4003F 1A
200V
3B4003 7R
D9 RECT F ER 1N4003F 1A
200V
3B4003 7R
D10 ZENER 5V6 400MW 3C05604 8R
D101 RECT F ER 1N4003F 1A
200V
3B4003 7R
D102 ZENER 10V 400MW 3C11004 7R
D103 ZENER 10V 400MW 3C11004 7R
D104 ZENER 10V 400MW 3C11004 7R
D105 RECT F ER 1N4003F 1A
200V
3B4003 7R
D106 RECT F ER 1N4003F 1A
200V
3B4003 7R
D107 RECT F ER 1N4003F 1A
200V
3B4003 7R
D108 ZENER 5V6 400MW 3C05604 7R
D201 ULTRAFAST RECT F ER
DIODE UF5403 3A
3B5403F 7R
D202 ULTRAFAST RECT F ER
DIODE UF5403 3A
3B5403F 7R
D203 ULTRAFAST RECT F ER
DIODE UF5403 3A
3B5403F 7R
D204 ULTRAFAST RECT F ER
DIODE UF5403 3A
3B5403F 7R
D801 ZENER 5V6 400MW 3C05604 7R
D802 ZENER 4V7 400MW 3C04704 7R
D803 SSDIODE 1N4148 75V 3A4148 7R
D901 RECT F ER 1N4003F 1A
200V
3B4003 7R
D902 ZENER 5V6 400MW 3C05604 7R
D903 RECT F ER 1N4003F 1A
200V
3B4003 7R
D904 ZENER 5V6 400MW 3C05604 7R
D905 SSDIODE 1N4148 75V 3A4148 7R
EL1 FUSE CLIP WCK-180-01A F062 7R
FS201 INS COVER PCB
FUSEHOLDER
F022 7R
FS201 FUSE 20mm 1.25A AS C12126 7R
FS201 FUSEHOLDER 20mm PCB 8S004 7R
FS202 FUSEHOLDER 20mm PCB 8S004 7R
FS202 INS COVER PCB
FUSEHOLDER
F022 7R
HS1 ALPHA AMP 7/8 HEATS NK E81801 7R
HS1 SIL PAD - 25 X 12.5mm E817MC 7R
HS1 ALPHA AMP 7/8 HS CLIP E810MC 7R
HS2 SIL PAD - 25 X 12.5mm E817MC 7R
HS2 ALPHA AMP 7/8 HEATS NK E81801 7R
HS2 ALPHA AMP 7/8 HS CLIP E810MC 7R
HS3 SIL PAD - 25 X 12.5mm E817MC 7R
