ALPHA 9/9P SERVICE MANUALALPHA 9/9P SERVICE MANUAL
Alpha 9P Power Amplifier Parts List
Ref. No. Description Part No.
C1 ELST 100U 25V 2N710
C2 PEST 47N 63V 5% 2K347
C3 ELST 100U 100V 2N710B
C4 PCRB 100N 100V 5% RA 5mm 2H410
C5 PPRO 680P 5% 63V RA 2D168
C6 PSTY 56P 160V ENCAP 1PF% 2F056
C7 ELST 10U 50V 2N610
C8 ELST 100U 25V 2N710
C9 PEST 15N 63V 5% 2K315
C10 PEST 15N 63V 5% 2K315
C11 PPRO 220P 5% 63V RA 2D122
C12 ELST NON POLAR 10UF 35V 2U610
C20 PEST 15N 63V 5% 2K315
C22 PCRB 100N 100V 5% RA 5mm 2H410
C23 PCRB 100N 100V 5% RA 5mm 2H410
C71 ELST 10U 50V 2N610
C72 ELST 100U 25V 2N710
C101 ELST 100U 25V 2N710
C102 PEST 47N 63V 5% 2K347
C103 ELST 100U 100V 2N710B
C104 PCRB 100N 100V 5% RA 5mm 2H410
C105 PPRO 680P 5% 63V RA 2D168
C106 PSTY 56P 160V ENCAP 1PF% 2F056
C107 ELST 10U 50V 2N610
C108 ELST 100U 25V 2N710
C109 PEST 15N 63V 5% 2K315
C110 PEST 15N 63V 5% 2K315
C111 PPRO 220P 5% 63V RA 2D122
C112 ELST NON POLAR 10UF 35V 2U610
C120 PEST 15N 63V 5% 2K315
C122 PCRB 100N 100V 5% RA 5mm 2H410
C123 PCRB 100N 100V 5% RA 5mm 2H410
Alpha 9P Power Amplifier Parts List
Ref. No. Description Part No.
C172 ELST 100U 25V 2N710
C173 ELST 100U 25V 2N710
C201 ELST 10m 50V RA 32mm 2N910
C202 ELST 10m 50V RA 32mm 2N910
C205 PPRO 4N7 63V 5% RA 2D247N
C206 PPRO 4N7 63V 5% RA 2D247N
C207 ELST 10U 50V 2N610
C208 ELST 10U 50V 2N610
C209 ELST 10U 50V 2N610
C210 ELST 10U 50V 2N610
C404 CERD 10N 63V 20% RA 2A310
C501 ELST 100U 25V 2N710
C502 ELST 1U0 50V 20% RA 2N510
C503 ELST 100U 25V 2N710
C504 ELST 1U0 50V 20% RA 2N510
C505 SUPPR CAP 4N7 250V 2K247
C506 CERD 10N 63V 20% RA 2A310
C507 CERD 1N0 63V 20% RA 2A210
C508 CERD 1N0 63V 20% RA 2A210
C509 CERD 1N0 63V 20% RA 2A210
C510 CERD 1N0 63V 20% RA 2A210
C511 CERD 1N0 63V 20% RA 2A210
C512 CERD 1N0 63V 20% RA 2A210
D1 ZENER 10V 400MW 3C11004
D2 RECTIFIER 1N4003F 1A 200V 3B4003
D3 ZENER 10V 400MW 3C11004
D4 ZENER 10V 400MW 3C11004
D5 ZENER 5V6 400MW 3C05604
D6 ZENER 22V 400MW 3C22004
D101 ZENER 10V 400MW 3C11004
D102 RECTIFIER 1N4003F 1A 200V 3B4003
D103 ZENER 10V 400MW 3C11004
