ALPHA 9/9P SERVICE MANUALALPHA 9/9P SERVICE MANUAL
SW202N SW ROTARY 6W 4 POLE A1210
SW205N SW PUSH 2PCO A1008
SW206N 2PC SLIDER SW MSS2200 A1401
SW207N SW PUSH 4PCO A1013
SW402N 2PC R/A SLIDE SW A1402
SW501 SW PUSH 2PCO A1008
SW502 SW PUSH 2PCO A1008
SW503 SWITCH PUSH MAINS OPST SDS3P A1006
TC1 TRANSFORMER CLAMP E00201
TC2 TRANSFORMER CLAMP E00201
TH501 THERMISTOR SIEMENS B59008 1T002
TX1 ALPHA9 MULTI VOLTAGE TRANSFORMER L817TX
X401N CER RESON CST4.19MG 4.19MHz 7W002
Y2 TX WIRE RESTRAINT F185
Y3 TX WIRE RESTRAINT F185
Y20 COPPER RIVET HP007
Y21 COPPER RIVET HP007
Z1 IC AUDIO NE5534N 5A5534
Z2N IC AUDIO DUAL JRC4560 5B4560
Z3 IC COMPARITOR DUAL LM393A 5M393A
Z101 IC AUDIO NE5534N 5A5534
Z102N IC AUDIO DUAL JRC4560 5B4560
Z201 IC VREG POS LM317T 5D317T
Z202 IC VREG POS LM337T 5D337
Z203N IC AUDIO DUAL TL072 5B072
Z401N IC SOCKET 18 PIN 0.3'' 8S018
Z401N IC CMOS MICRO PIC16C54XT/P 5H16C54X
Z402N MOTOR DRIVER 5Q6109 5Q6109
Z403N MOTOR DRIVER 5Q6109 5Q6109
Z501 IC COMPARITOR TA7317P 5M7317
Alpha 9 Amplifier Non PCB Parts, Metalwork etc.
Part No. Description
B3002 AA BATTERY FOR REMOTE CONTROL
E66801 REAR PHONO INPUT BLANKING PLATE
E802CH CHASSIS
E802MI PCB INSULATOR
E803SP ALPHA 9/9P AMP SUBPANEL
E804AP FELT RING
E804CP ALPHA 9/9P COVERPLATE
E808RP REAR PANEL
E813FP ALPHA 9 FASCIA
E815PM POWER BUTTON
E818PM VOLUME KNOB
E819PM BALANCE/TREBLE/BASS KNOB
E820PM LISTEN KNOB
E822PM FOOT
E825PM ALPHA 9 BADGE
E901HK HEATSINK ANODISED
F037 TOROIDIAL TRANSFORMER CLAMP
F038 RUBBER WASHER FOR ABOVE
HA6K55A TRANSFORMER BOLT
L802RC HANDI REMOTE CONTROL
SH053 OWNERS HANDBOOK
SH058 WARRANTY LEAFLET
