ALPHA 9/9P SERVICE MANUALALPHA 9/9P SERVICE MANUAL
R207 RES MF FU W3 10R 5% NFR25 1G010
R401N RES MF FU W3 10R 5% NFR25 1G010
R402N RES MF W4 1K0 1% 1H210
R403N RES MF W4 1K0 1% 1H210
R404 RES MF FU W3 1R0 5% NFR25 1G810
R405N RES MF W4 1K0 1% 1H210
R406N RES MF W4 4K7 1% 1H247
R407N RES MF W4 4K7 1% 1H247
R408N RES MF W4 470R 1% 1H147
R410N RES CF 1W 2K7 5% 1E227
R501 RES MF W4 47K 1% 1H347
R502 RES MF W4 47K 1% 1H347
R503 RES MF W4 100R 1% 1H110
R504 RES MF W4 47K 1% 1H347
R505 RES MF W4 47K 1% 1H347
R506 RES MF W4 100K 1% 1H410
R507 RES MF W4 18K 1% 1H318
R508 RES MF W4 47K 1% 1H347
R509 RES MF W4 47K 1% 1H347
R510 RES MF W4 100K 1% 1H410
R511 RES MF W4 18K 1% 1H318
R512 RES MF W4 18K 1% 1H318
R513 RES MF W4 33K 1% 1H333
R514 RES MF W4 47K 1% 1H347
R515 RES CF 1W 1K0 5% 1E210
R516 RES CF 1W 1K0 5% 1E210
R517 RES CF 1W 2K7 5% 1E227
R518 RES CF 1W 2K7 5% 1E227
R519 RES CF 1W 330R 5% 1E133
R520 RES CF 1W 330R 5% 1E133
R521N RES CF 1W 2K7 5% 1E227
R524 RES MF W4 18K 1% 1H318
R525 RES CF W2 100R 5% 1D110
R526 RES CF W2 100R 5% 1D110
R527 RES MF W4 10R 1% 1H010
R601N RES MF W4 22R 1% 1H022
R602N RES MF W4 22R 1% 1H022
R603N RES MF W4 6K8 1% 1H268
R604N RES MF W4 2K2 1% 1H222
R605N RES MF W4 6K8 1% 1H268
R606N RES MF W4 2K2 1% 1H222
RA1 RES MO 3W 5% 0R22 KOASPR3 1Q922
RA101 RES MO 3W 5% 0R22 KOASPR3 1Q922
RLY401N RELAY 960 OHM 51SB12T A205
RLY501 RELAY G5Z-2A-E 24V A207
RLY502 RELAY G5Z-2A-E 24V A207
RLY503N RELAY 960 OHM 51SB12T A205
RP401N RES NETWORK 100Kx8 COMMON 1V410
RV201N POT 20KA* 2 LIN A 6A320E
RV202N POT 20KA* 2 LIN A 6A320E
RV203N POT 20KA* 2 LIN A 6A320E
RV601N POT 20KA* 2 LOG A MOTORISED 6A330M
RX1N REMOTE CONTROL RECEIVER SBX1610-62 38KHZ B2103
SK501 BINDING POST 4WAY GOLD LTS04102002G 8D416
SK502 BINDING POST 4WAY GOLD LTS04102002G 8D416
SK201N PRESSACTL 8-WAY MALE VERT 8K5181
SK301N PHONO SKT 4-WAY EMC GOLD 8D225
SK302N PHONO SKT 4-WAY EMC GOLD 8D225
SK303N PHONO SKT 4-WAY EMC GOLD 8D225
SK304N PHONO SKT 4-WAY EMC GOLD 8D225
SK305 PHONO SKT 4-WAY EMC GOLD 8D225
SK503 IEC MAINS CONN PCB INS PX 8A001
SK504 STEREO JACK PCB 8D301
SK601N JUMPER 2 W LEAD APL5 1Y271
SK602N JUMPER 8-WAY LEAD L809CA
SPRFS SPARE FUSEHOLDER F062
SPRFS SPARE FUSE 20mm 1.6A AS C12166
SW201N SWITCH ROTARY 6W MOTOR A1207
