Arcam ALPHA ONE Service Manual

H / P P S E MANALPHA ONE/7R/8R/8P AMPLIFIER SERVICE MANUAL
10
SW201 SW PUSH MA NS
SDDSA32MZU
A1007 7R
SW302 SW PUSH 4PCO A1013 8R
SW305 SWITCH SRBU 150 44A A1202 7R
SW305 SWITCH 4POLE SRBU
5WAY
A1212 8R
TX1 ALPHA 7 AMP MULTI
VOLTAGE TRANSFORM
L835TX 7R
TX1 ALPHA 1/5.2
TRANSFORMER 230V
L841TX A1
TX1 ALPHA 8 AMP MULTI
VOLTAGE TRANSFORM
L833TX 8R/8P
VOLMOT JUMPER 2 W LEAD APL5 1Y271 7R
X901 CER RESON CST4.19MG
4.19MHz
7W002 7R
Y1 TX WIRE RESTRAINT F185 7R
Y2 TX WIRE RESTRAINT F185 7R
Z201 IC VREG POS 7815 5D7815 7R
Z202 IC VREG NEG 7915 5D7915 7R
Z300 IC AUDIO DUAL 4560D 5B4560 7R
Z301 IC AUDIO DUAL NE5532N 5A5532 A1
Z302 IC AUDIO DUAL 4560D 5B4560 7R
Z303 IC COMPARITOR TA7317P 5M7317 7R
Z304 IC AUDIO DUAL 4560D 5B4560 7R
Z305 IC AUDIO DUAL NE5532N 5A5532 7R
Z305 IC AUDIO DUAL OP275 5B275 8R
Z801 IC HCMOS PC74HC4052P
ONLY
5F4052P 7R
Z901 IC SOCKET 18 P N 0 3'' 8S018 7R
Z901 IC CMOS MICRO
PIC16C54XT/P
5H16C54X 7R
Z902 MOTOR DRIVER 5Q6109 5Q6109 7R
