Arcam ALPHA ONE Service Manual

H / P P S E MANALPHA ONE/7R/8R/8P AMPLIFIER SERVICE MANUAL
9
R510 RES MF W4 3K3 1% 1H233 7R
R510 RES MF W4 6K8 1% 1H268 A1
R511 RES MF W4 1% 4K7 1H247 7R
R511 RES MF W4 10K 1% 1H310 A1
R512 RES MF W4 1% 10K 1H310 7R
R512 RES MF W4 18K 1% 1H318 A1
R515 RES MF W4 3K3 1% 1H233 7R
R516 RES MF W4 1% 1K8 1H218 7R
R601 RES MF W4 1% 47K 1H347 7R
R602 RES MF W4 1% 470R 1H147 7R
R603 RES MF W4 1% 680K 1H468 7R
R604 RES MF W4 1% 56K 1H356 7R
R605 RES MF W4 1% 820R 1H182 7R
R701 RES MF W4 1% 47K 1H347 7R
R702 RES MF W4 1% 470R 1H147 7R
R703 RES MF W4 1% 680K 1H468 7R
R704 RES MF W4 1% 56K 1H356 7R
R705 RES MF W4 1% 820R 1H182 7R
R801 RES MF W4 1% 4K7 1H247 7R
R801 RES MF W4 560R 1% 1H156 8P
R802 RES MF W4 1% 100K 1H410 7R
R802 RES MF W4 3K9 1% 1H239 8P
R803 RES MF W4 1% 2K4 1H224 7R
R804 RES MF W4 1% 5K6 1H256 7R
R805 RES MF W4 1% 4K7 1H247 7R
R805 RES MF W4 560R 1% 1H156 8P
R806 RES MF W4 1% 100K 1H410 7R
R806 RES MF W4 3K9 1% 1H239 8P
R807 RES MF W4 1% 2K4 1H224 7R
R808 RES MF W4 1% 5K6 1H256 7R
R809 RES MF W4 1% 100K 1H410 7R
R810 RES MF W4 1% 100K 1H410 7R
R811 RES MF W4 1% 220R 1H122 7R
R812 RES MF W4 1% 220R 1H122 7R
R813 RES MF W4 1% 22K 1H322 7R
R814 RES MF W4 1% 22K 1H322 7R
R815 RES MF W4 1% 1K2 1H212 7R
R816 RES MF W4 1% 1K2 1H212 7R
R817 RES MF W4 18K 1% 1H318 7R
R818 RES MF W4 1% 8K2 1H282 8P
R819 RES MF W4 1% 8K2 1H282 8P
R901 RES MF FU W3 1R0 5%
NFR25
1G810 7R
R902 RES MF W4 1% 100R 1H110 7R
R903 RES MF W4 1% 100R 1H110 7R
R904 RES MF W4 1% 1K8 1H218 7R
R905 RES MF W4 1% 4K7 1H247 7R
RLY1 RELAY G5Z-2A-E 24V A207 7R
RLY2 RELAY 960 OHM 51SB12T A205 8R
RV1 10K PSET 6F310 7R
RV101 10K PSET 6F310 7R
RV301 POT 20KA* 2 LOG A 6A320L A1
RV302 POT 10KB* 2 LIN 6A310E 7R
RV303 POT 10KB* 2 LIN 6A310E 7R
RV304 POT 10KB* 2 LIN 6A310E 7R
RV901 POT 20KA DUAL 18MM
MOTORISED
6A360M 7R
RX1 REMOTE CONTROL
RECEIVER SBX1610-62
B2103 7R
SK1 CAMCON BIND NG POST
4WAY NICKEL
8D418 7R
SK1 CANCON B ND NG POST
4WAY GOLD
8D418G 8R/8P
SK2 CAMCON BIND NG POST
4WAY NICKEL
8D418 7R
SK2 CANCON B ND NG POST
4WAY GOLD
8D418G 8R/8P
SK3 STEREO JACK PCB 8D301 7R
SK4 CAGE CLAMP 16A 3 WAY
ARC001-236
8Q001 7R
SK5 CAGE CLAMP 16A 1 WAY
ARC003-236
8Q003 7R
SK6 CAGE CLAMP 16A 2WAY
236-402/000-009
8Q005 7R
SK7 CAGE CLAMP 16A 3 WAY
ARC004-236
8Q004 7R
SK201 IEC MAINS CONN PCB NS
PX
8A001 7R
SK301 PHONO SKT 4-WAY EMC 8D224 7R
SK301 PHONO SKT 4-WAY EMC
GOLD
8D225 8R/8P
SK302 PHONO SKT 4-WAY EMC 8D224 7R
SK302 PHONO SKT 4-WAY EMC
GOLD
8D225 8R/8P
SK303 PHONO SKT 4-WAY EMC 8D224 7R
SK303 PHONO SKT 4-WAY EMC
GOLD
8D225 8R/8P
SK304 PHONO SKT 4-WAY EMC 8D224 7R
SK304 PHONO SKT 4-WAY EMC
GOLD
8D225 8R/8P
SW1 SWITCH SLIDE 2WAY C/O
PANEL MNT PCB
A1403 8R
