CD73 COMPACT DISC PLAYER
- 3 -
1765432
12 3 45 67
FRONT PANEL & REAR PANEL
1. FRONT PANEL
2. REAR PANEL
1. POWER
2. LOAD
3. PLAY
4. STOP
5. PAUSE
6. SEARCH
7. SKIP TRACK
1. SOCKET FOR IEC POWER INLET LINE
2. VOLTAGE SELECTOR SWITCH
3. AUDIO OUTPUT SOCKETS
4. COAXIAL DIGITAL OUTPUT SOCKET
5. OPTICAL DIGITAL OUTPUT SOCKET
6. REMOTE IR INPUT
7. 12V TRIGGER INPUT
