EN / 20
6.2 Symbols on the Display
1 2 3 4 5 6
7891011121314
1 Temperature Indicator 2 Spin Speed Indicator
3 Duration Information 4 Door Lock Is Engaged Symbol
5 Programme Follow-up Indicator 6 No Water Indicator
7 Delayed Start Enabled Indicator 8 Auxiliary Function Indicators 3
9 Auxiliary Function Indicators 2 10 Child Lock Enabled Symbol
11 Auxiliary Function Indicators 1 12 No Spin Indicator
13 Rinse Hold Indicator 14 Cold Water Indicator
The visuals used for machine de-
scription in this section are schem-
atic and may not match exactly
with the features of your machine.
