DV - 520
14
INSTALLATION INSTRUCTIONS Cont...
For best venting performance, here are some general venting rules that we recommend:
1. Use only Archgard, Simpson Dura-Vent or Metal-fab direct vent systems and components.
2. Maintain a minimum of 1” (26 mm) clearance to combustibles from the outside surfaces of
vertical vents and minimum of 1” (26 mm) sides and bottom, and 2” (51 mm) from top
surfaces of horizontal vents.
3. Observe any local code restrictions, if any, regarding the installation of this type of gas
appliance.
4. Observe the venting chart given in this manual.
5. Use vent spacers between the inside and outside vents at 3 ft (915 mm) intervals (Archgard
vent kits only).
6. Never slope horizontal vents downwards.
7. Maintain at least a rise of 1/4” (7 mm) for every 1 ft (305 mm) of horizontal vent.
8. Terminate the vent with a vent termination cap (for horizontal terminations) supplied by
Archgard Part # TK-1 or (for vertical terminations) Simpson Dura Vent or Metal-fab.
9. Support horizontal vents every 3 ft (915 mm) to prevent it from sagging.
VENTING Cont...
VENTING CONNECTION
The intake pipe shall be securely fastened to the appliance and to the terminal and all joints shall be
secured using a minImum of 3 screws evenly spaced around the pipe.
Approximately 1” from the end of the 4” pipe outlet at the appliance and at the 4” terminal inlet apply a
bead of Mil Pac 1/4” wide. Slide the 4” pipe onto the appliance and secure with 3 screws evenly spaced
to the outlet. Repeat the procedure at the termination cap.
Install a vent spacer between the outer and the inner liner to maintain clearances. Spacers shall be
installed at every 3 Ft of horizontal run and at every change of direction. (See diagram)
Clearance to combustible material and fire-stops shall be install as required by the installation codes
.
APPROVED VENT COMPONENTS
PART # DESCRIPTION
TVK-1 Horizontal Flex Vent Kit with 36” vent length (includes TK-1)
TVK-2 Horizontal Flex Vent Kit with 60” vent length (includes TK-1)
TK-1 Horizontal termination head only
VSD-1 Vinyl siding deflector
SDA-1 Adaptor, Flex to Simpson Dura-Vent
SDA-3 Adaptor, Appliance to Simpson Dura-Vent
DV-GS Simpson Dura-Vent venting system
TDV series Metal-fab venting system
