Optima 45 - 3 8
APPLIANCE DIMENSIONS
APPLIANCE DESCRIPTION
MAIN CONTROL PANEL
UPPER LOUVERS
GLASS DOOR
LOWER LOUVERS
DIMENSIONS
A HEIGHT 30” (762 mm)
B WIDTH 27” (685 mm)
C DEPTH 17 ½” (444 mm)
A
C
B
