ENGLISH
DESCRIPTION OF THE DEVICE
Hardware Reset: In the event that your ARCHOS freezes operation, you can press the “pinhole reset” button,
located on the back the device, by using a sharp object such as a toothpick.
Power/Lock: slide left and hold to switch on/off. Slide right to lock the
device’s touchscreen.
When you slide left and hold, a window appears with a list of options (when the product is on).
Tap on “Power Off” to fully shut down your ARCHOS. Tap on “Suspend” to put the device in
standby (and allow a quick start up when you next tap the screen). While the device is in suspend
mode, slide right to lock the device with its screen off. This can be useful if your ARCHOS is in your
backpack, for example, and you do not want to wake it up by touching the screen by accident.
Micro-SD card reader
Charging indicator: Red light: battery charging / Yellow: battery charged.
Loudspeakers
Headphone jack
Power connector: to connect the supplied power cable.
USB port: to connect your ARCHOS to your computer, using the included USB cable. You can also connect a keyboard, a mouse
or a mass storage USB device (for example a USB stick), using the optional USB host adapter available at www.archos.com
Leg stand: pull it out, and it will allow your ARCHOS to stand by itself on a flat, stable surface.
