ARCO LI-2B - Page 21

Auto
Reverse
Motor 1 & 2
c/wise =
less force
Auto Close
Anti-c/wise
to increase
hold open
time
Travel Time
c/wise =
minimum
Travel Time
Close
Dela
y
Open
Delay
c/wise =
Maximum
Delay
Travel
T
ime LED
Three Pin
Block
Jumper on
1 & 2 =
Auto Close
Jumper on
2 & 3 =
Manual
Close
0.5A Fuse
DC In
Negative
Positive
Battery
Negative
Positive
10A Fuse
Motor 1
Open
Close
Motor 2
Open
Close
Photoelectric
Safet
y
Electric Lock
Negative
Positive
Open
LED
Green
Close
LED
Red
Push
Button
LI-2B Installation Manual
