Arcora BLANCUS 40 - Page 11

11
110
Handle attachment
(front)
111
Water tank locator
112
M6X16 round head
screw
113
40X2 aluminum handle
114
M6X16 round head
screw
115
Electric wire
116
M6X16 cylinder head
screw
117
Sewage tank suction
liner
118
M6 round head nut
119
Aluminum tube closure
120
Wire sheath
Explosion diagram 2
Number
Name
Number
Name
Number
Name
