8-16
2. Inspect all wires for corroding, pinching, and crack-
ing.
3. Inspect the bulb for wattage, voltage, and proper
operation.
INSTALLING
1. Place the assembly into position on the frame and
secure with torx-head cap screws and any washers.
2. Tighten the cap screws securely.
3. Route the wiring harness over the rear frame; then
connect the three-prong connector.
Seat
REMOVING/INSTALLING
1. To remove the seat, lift up on the latch release
(located at the rear of the seat). Raise the rear of the
seat and slide it rearward.
2. To lock the seat into position, slide the front of the
seat into the seat retainers and push down firmly on
the rear of seat. The seat should automatically lock
into position.
Troubleshooting
Problem: Handling too heavy or stiff
Condition Remedy
1. Front wheel alignment incorrect
2. Lubrication inadequate
3. Tire inflation pressure low
4. Tie rod ends seizing
5. Linkage connections seizing
1. Adjust alignment
2. Lubricate appropriate components
3. Adjust pressure
4. Replace tie rod ends
5. Repair - replace connections
Problem: Steering oscillation
Condition Remedy
1. Tires inflated unequally
2. Wheel(s) wobbly
3. Wheel hub cap screw(s) loose - missing
4. Wheel hub bearing worn - damaged
5. Tie rod ends worn - loose
6. Tires defective - incorrect
7. A-arm bushings damaged
8. Bolts - nuts (frame) loose
1. Adjust pressure
2. Replace wheel(s)
3. Tighten - replace cap screws
4. Replace bearing
5. Replace - tighten tie rod ends
6. Replace tires
7. Replace bushings
8. Tighten bolts - nuts
Problem: Steering pulling to one side
Condition Remedy
1. Tires inflated unequally
2. Front wheel alignment incorrect
3. Wheel hub bearings worn - broken
4. Frame distorted
5. Shock absorber defective
1. Adjust pressure
2. Adjust alignment
3. Replace bearings
4. Repair - replace frame
5. Replace shock absorber
Problem: Tire wear rapid or uneven
Condition Remedy
1. Wheel hub bearings worn - loose
2. Front wheel alignment incorrect
3. Tire inflation pressure incorrect
1. Replace bearings
2. Adjust alignment
3. Adjust pressure
Problem: Steering noise
Condition Remedy
1. Cap screws - nuts loose
2. Wheel hub bearings broken - damaged
3. Lubrication inadequate
1. Tighten cap screws - nuts
2. Replace bearings
3. Lubricate appropriate components
