General Specifications*
* Specifications subject to change without notice.
Break-In Procedure
A new ATV and an overhauled ATV engine require a
“break-in” period. The first 10 hours (or 200 miles) are
most critical to the life of this ATV. Proper operation
during this break-in period will help assure maximum
life and performance from the ATV.
During the first 10 hours (or 200 miles) of operation,
always use less than 1/2 throttle. Varying the engine
RPM during the break-in period allows the compo-
nents to “load” (aiding the mating process) and then
“unload” (allowing components to cool). Although it
is essential to place some stress on the engine compo-
nents during break-in, care should be taken not to
overload the engine too often. Do not pull a trailer or
carry heavy loads during the 10-hour break-in period.
When the engine starts, allow it to warm up properly.
Idle the engine several minutes until the engine has
reached normal operating temperature. Do not idle the
engine for excessively long periods of time.
During the break-in period, a maximum of 1/2 throttle
is recommended; however, brief full-throttle accelera-
tions and variations in driving speeds contribute to
good engine break-in.
During the break-in period (or whenever the brake
pads are replaced), the hydraulic brake pads must be
burnished. Slow disc-speed hydraulic brakes must be
properly burnished in order to achieve maximum stop-
ping power.
NOTE: Do not be reluctant to heat up the brake
pads during the burnishing procedure.
After the completion of the break-in period, the engine
oil and oil filter should be changed. Other maintenance
after break-in should include checking of all pre-
scribed adjustments and tightening of all fasteners.
Gasoline - Oil -
Lubricant
RECOMMENDED GASOLINE
The recommended gasoline to use is 87 minimum
octane regular unleaded. In many areas, oxygenates
(either ethanol or MTBE) are added to the gasoline.
Oxygenated gasolines containing up to 10% ethanol,
5% methane, or 5% MTBE are acceptable gasolines.
CHASSIS
Dry Weight (approx) 169 kg (373 lb)
Length (overall) 183 cm (72 in.)
Height (overall) 116 cm (45.7 in.)
Width (overall) 116.5 cm (45.8 in.)
Suspension Travel Front - 21.6 cm (8.5 in.)
Rear - 23.1 cm (9.1 in.)
Ground Clearance 26.5 cm (10.4 in.)
Brake Type Hydraulic Disc and Mechanical
Parking Brake
Wheelbase 124.5 cm (49 in.)
Tire Size Front - AT22 x 7R10
Rear - AT20 x 10R9
Tire Inflation Pressure Front - 0.30 kg/cm² (4.4 psi)
Rear - 0.275 kg/cm² (4.0 psi)
Turning Radius 3.1 m (10.2 ft)
MISCELLANY
Gas Tank Capacity (rated) 10.0 L (2.6 U.S. gal.)
Reserve Capacity 0.7 L (0.18 U.S. gal.)
Engine Oil Capacity 2.1 L (2.2 U.S. qt)
Gasoline (recommended) 87 Octane Regular Unleaded
Engine Oil (recommended) SAE 10W-40
Cooling System Capacity 1.2 L (1.3 U.S. qt)
Brake Fluid DOT 4
Taillight/Brakelight 12V/5W/21W
Headlight 12V/27W (2)/12V/50W (1)
Starting System Electric
! CAUTION
BRAKE PADS MUST BE BURNISHED TO ACHIEVE
FULL BRAKING EFFECTIVENESS. Braking distance
will be extended until brake pads are properly bur-
nished.
TO PROPERLY BURNISH THE BRAKES, USE FOL-
LOWING PROCEDURE:
• Choose an area sufficiently large to safely accel-
erate ATV to 30 mph and to brake to a stop.
• Accelerate to 30 mph; then apply front and rear
brakes to decelerate to 0-5 mph.
• Repeat procedure five times.
• This procedure burnishes the brake pads, stabi-
lizes the pad material, and extends the life of the
brake pads.
! WARNING
Do not attempt sudden stops or put the ATV into a
situation where a sudden stop will be required until
the brake pads are properly burnished.
