Page 5
LOCATION OF PARTS AND CONTROLS
MODEL DVX 400
1. Tool storage (under the seat)
2. Reverse lever
3. Gearshift Pedal
4. Battery (under the seat)
5. Fuel valve
8
1
9
5
6
3
4
Page 6
6. Seat Lock
7. Foot Brake Pedal (main brake)
8. Parking Brake
9. Taillight/Brake Light/Registration number
2
