Arctic EF6100+ - Drainage and Initial Operation

4 / EN
Washing Machine / User’s Manual
2.5 Connecting to the drain
• Theendofthedrainhosemustbedirectlyconnectedto
thewastewaterdrainortothewashbasin.
A WARNING
Donotremovethetransportationlocksbeforetakingoutthe
packaging reinforcement.
• Thehoseshouldbeattachedtoaheightofatleast40cm,
and 100 cm at most.
• Incasethehoseiselevatedafterlayingitonthefloorlevel
orclosetotheground(lessthan40cmabovetheground),
waterdischargebecomesmoredifficultandthelaundry
maycomeoutexcessivelywet.Therefore,followthe
heightsdescribedinthefigure.
• Topreventflowingofdirtywaterbackintothemachineand
toallowforeasydischarge,donotimmersethehoseend
into the dirty water or do not drive it in the drain more than
15cm.Ifitistoolong,cutitshort.
• Theendofthehoseshouldnotbebent,itshouldnotbe
steppedonandthehosemustnotbepinchedbetweenthe
drain and the machine.
• Ifthelengthofthehoseistooshort,useitbyadding
an original extension hose. Length of the hose may not
belongerthan3.2m.Toavoidwaterleakfailures,the
connectionbetweentheextensionhoseandthedrain
hoseoftheproductmustbefittedwellwithanappropriate
clamp as not to come off and leak.
2.6 Adjusting the feet
A WARNING
Inordertoensurethattheproductoperatesmoresilentlyand
vibration-free,itmuststandlevelandbalancedonitsfeet.Balance
themachinebyadjustingthefeet.Otherwise,theproductmay
movefromitsplaceandcausecrushingandvibrationproblems.
Loosenthelocknutsonthefeetbyhand.Adjustthefeetuntil
theproductstandslevelandbalanced.Tightenalllocknuts
againbyhand.
A WARNING
Donotuseanytoolstoloosenthelocknuts.Otherwise,theywill
get damaged.
2.7 Electrical connection
Connecttheproducttoagroundedoutletprotectedbyafuse
complyingwiththevaluesinthe"Technicalspecifications"
table.Ourcompanyshallnotbeliableforanydamagesthat
will arise when the product is used without grounding in
accordance with the local regulations.
• Connectionmustcomplywithnationalregulations.
• Powercableplugmustbewithineasyreachafter
installation.
• Thevoltageandallowedfuseorbreakerprotectionare
specifiedinthe“Technicalspecifications”section.Ifthe
currentvalueofthefuseorbreakerinthehouseisless
than16Amps,haveaqualifiedelectricianinstalla16Amp
fuse.
• Thespecifiedvoltagemustbeequaltoyourmainsvoltage.
• Donotmakeconnectionsviaextensioncablesormulti-
plugs.
B WARNING
DamagedpowercablesmustbereplacedbytheAuthorizedService
Agents.
2.8 First use
Beforestartingtousetheproduct,makesurethatall
preparations are made in accordance with the instructions in
sections"Importantsafetyinstructions"and"Installation".
Topreparetheproductforwashinglaundry,performfirst
operationinCotton-90programme.Beforestartingthe
programme,putmax.100gofpowderanti-limescaleinto
themainwashdetergentcompartment(compartmentnr.II).
Iftheanti-limescaleisintabletform,putonlyonetabletinto
compartmentnr.II.Drytheinsideofthebellowwithaclean
piece of cloth after the programme has come to an end.
C
INFORMATIONS
Useananti-limescalesuitableforthewashingmachines.
Somewatermighthaveremainedintheproductduetothequality
controlprocessesintheproduction.Itisnotharmfulfortheproduct.
2.9 Disposing of packaging material
Packagingmaterialsaredangeroustochildren.Keep
packaging materials in a safe place away from reach of the
children.
Packagingmaterialsoftheproductaremanufacturedfrom
recyclablematerials.Disposeofthemproperlyandsortin
accordancewithrecycledwasteinstructions.Donotdispose
of them with normal domestic waste.
2.10 Transportation of the product
Unplugtheproductbeforetransportingit.Removewaterdrain
andwatersupplyconnections.Draintheremainingwaterin
theproductcompletely;see,"Drainingremainingwaterand
cleaningthepumpfilter".Installtransportationsafetyboltsin
thereverseorderofremovalprocedure;see,"Removingthe
transportationlocks".
C
INFORMATIONS
Nevermovetheproductwithoutthetransportationsafetybolts
properly fixed in place!
