Arden BLN-012TC3 - User Manual

Questions and Answers

C
Catherine WatsonAug 19, 2025
What to do if my Arden Heat Pump displays E03 error related to water flow?
- M
  Melissa JimenezAug 19, 2025
  If your Arden Heat Pump shows an E03 error, indicating a water flow issue, take these steps: First, ensure the pipeline valve is fully open to allow clear water flow. Next, check if the water flow switch is correctly installed and is the right model. Also, verify that the connection line of the water flow switch is correctly inserted into port D13 (white). Then, check if the circulating water pump is functioning normally and that the water system isn't blocked. After that, inspect the water pump's head and flow to ensure they're sufficient; if not, consider adding a hot water auxiliary pump. Finally, check whether any external auxiliary pump is working in reverse.
J
James CortezAug 21, 2025
How to troubleshoot E05 High voltage switch failure in Arden BLN-012TC3?
- C
  cisnerosdawnAug 21, 2025
  To troubleshoot the E05 error on your Arden Heat Pump, follow these steps: First, check the high-pressure pressure switch for damage and ensure the wiring terminals are correctly connected to the D11 (red) port. Then, use a pressure gauge connected to the low-pressure inspection port to measure the amount of refrigerant in the system. Next, check the system for blockages or air. Use a pressure gauge to connect the high and low pressure inspection ports simultaneously to measure the system's operating pressure. After that, verify that the fan and water pump are operating normally and that the unit's water flow is normal. Lastly, inspect the water side heat exchanger for fouling; if severe, clean it with oxalic acid and citric acid, or install a cold water pre-filter.
P
Patricia StevensonAug 23, 2025
What should I do if my Arden BLN-012TC3 Heat Pump shows an E06 Low voltage switch failure?
- J
  Jonathan BlackwellAug 23, 2025
  If your Arden Heat Pump displays an E06 error, follow these steps: First, check the low-pressure pressure switch for damage and verify the wiring terminals are correctly connected to the D12 (blue) port. Then, use a pressure gauge to check for refrigerant loss at the low-pressure inspection port. If needed, add refrigerant and check for leaks at copper pipe welding joints using foam. Next, ensure the fan is working correctly and check the system for blockages. Use a pressure gauge to connect to both high and low pressure inspection ports to measure the system's operating pressure.
S
Susan BenderAug 26, 2025
How do I fix an E12 error (Exhaust temperature too high) on my Arden Heat Pump?
- T
  Todd ValdezAug 26, 2025
  To address an E12 error on your Arden Heat Pump, start by checking the system for blockages or insufficient refrigerant. Use a pressure gauge to connect to both high and low pressure inspection ports to assess the system's operating pressure. Also, inspect the exhaust gas temperature sensor for damage and use a multimeter to confirm that its resistance value is correct at the T3 (red) port.
O
Olivia MyersAug 28, 2025
What does E37 error mean on my Arden BLN-012TC3 and how do I fix it?
- N
  Nicolas PorterAug 28, 2025
  If your Arden Heat Pump displays an E37 error, indicating a large temperature difference between inlet and outlet water, follow these steps: First, ensure the pipeline valve is fully open. Next, check if the water pump is working correctly. Then, verify that the pump's rated head and flow meet the machine's operational requirements. Finally, manually drain the drain pump and any air in the pipe.
E
Elijah GuzmanAug 30, 2025
Why is my Arden Heat Pump showing an E02 Phase loss fault?
- M
  mary85Aug 30, 2025
  If your Arden Heat Pump is showing an E02 error, follow these steps: First, check that the power cord is securely connected. Then, use a multimeter to measure whether there is 220V voltage between the neutral wire and each live wire (this should be measured while the power is on). Finally, use a multimeter to measure whether there is 380V voltage between the three live wires (also measured under power-on state). Note that 220V machines will not have this failure.
T
Tina DudleySep 1, 2025
What to do if my Arden Heat Pump shows E14 Hot water tank temperature failure?
- T
  Tiffany DavisSep 1, 2025
  If your Arden Heat Pump displays the E14 error, it indicates a hot water tank temperature sensor failure. This could be due to: 1) an open or disconnected sensor connection line, 2) a damaged sensor, or 3) a damaged motherboard port. You can use a multimeter to measure whether the resistance is correct at the T16 (blue) port.
M
Margaret LopezSep 3, 2025
What does E15 error mean on my Arden BLN-012TC3?
- M
  mthomasSep 3, 2025
  If your Arden Heat Pump shows an E15 error, it indicates a failure with the inlet water temperature sensor. Possible causes include: 1) an open or disconnected sensor connection line, 2) a damaged sensor, or 3) a damaged motherboard port. Use a multimeter to check if the resistance is correct at the T8 (white) port.
R
Renee HansenSep 5, 2025
How do I resolve an E09 Communication failure between the wire controller and the main board on my Arden Heat Pump?
- H
  Heidi CookSep 5, 2025
  To resolve an E09 error on your Arden Heat Pump, first check whether the communication between the wire controller and the main board is normal. Then, use a multimeter to measure whether the voltage output of the motherboard port (white port) is normal.
M
Mary BrooksSep 7, 2025
What does E16 Coil sensor failure mean on Arden BLN-012TC3 Heat Pump?
- M
  Marissa CooperSep 7, 2025
  If your Arden Heat Pump displays the E16 error, it means there is a coil sensor failure. This may be due to: 1) the sensor connection line being open or disconnected, 2) the sensor being damaged, or 3) the motherboard port being damaged. Use a multimeter to measure whether the resistance value is correct at the TI (red) port.

Summary

Product Information

Product Models and Specifications

Visuals and detailed technical specifications for various heat pump models.

System Diagrams and Performance Curves

Explains system operation, diagrams, and graphical performance data under various conditions.

Installation and Precautions

Installation Guidelines and Safety

Essential guidelines, safety measures, and precautions for unit installation.

Pipeline and Electrical Wiring

Covers pipeline installation, pressure testing, insulation, and electrical wiring precautions.

Room Heat Load Calculation

Explains calculation of heat load requirements for different room types and conditions.

Electrical Operation and Control

Control Functions and Modes

Describes control functions, modes, and operational logic for pumps, compressors, and protections.

Wire Controller Interface and Operation

Guides users on interacting with the wire controller for unit display, settings, and operation.

Unit Configuration, Wiring, and Ports

Covers configuration, control box layouts, port definitions, and wiring diagrams for different models.

Waterway Systems and Diagnostics

Waterway Installation and Diagrams

Provides guidance on installing and wiring water circuits, showing various system configurations.

Fault Diagnosis and Troubleshooting

Guides on identifying and resolving common errors, including maintenance tools and procedures.

Technical Data and Schedules

NCT Sensor Resistance Table

Lists NCT sensor resistance values at different temperatures for calibration and diagnostics.

Ground Heat Dissipation Data

Provides data on heat dissipation and loss from the ground for various pipe types and conditions.

Water Expansion Coefficients

Lists water expansion coefficients at various temperatures for system calculations.

Arden BLN-012TC3 Specifications

General

Brand	Arden
Model	BLN-012TC3
Category	Heat Pump
Language	English
