Arden BLN-018TC3 - User Manual

Questions and Answers

A
Antonio SkinnerAug 19, 2025
What to do if my Arden BLN-018TC3 Heat Pump displays E03 error related to water flow?
- P
  pgonzalezAug 19, 2025
  If your Arden Heat Pump shows an E03 error, indicating a water flow issue, take these steps: First, ensure the pipeline valve is fully open to allow clear water flow. Next, check if the water flow switch is correctly installed and is the right model. Also, verify that the connection line of the water flow switch is correctly inserted into port D13 (white). Then, check if the circulating water pump is functioning normally and that the water system isn't blocked. After that, inspect the water pump's head and flow to ensure they're sufficient; if not, consider adding a hot water auxiliary pump. Finally, check whether any external auxiliary pump is working in reverse.
M
Matthew GilbertAug 21, 2025
How to troubleshoot E05 High voltage switch failure in Arden BLN-018TC3 Heat Pump?
- L
  Linda YoungAug 21, 2025
  To troubleshoot the E05 error on your Arden Heat Pump, follow these steps: First, check the high-pressure pressure switch for damage and ensure the wiring terminals are correctly connected to the D11 (red) port. Then, use a pressure gauge connected to the low-pressure inspection port to measure the amount of refrigerant in the system. Next, check the system for blockages or air. Use a pressure gauge to connect the high and low pressure inspection ports simultaneously to measure the system's operating pressure. After that, verify that the fan and water pump are operating normally and that the unit's water flow is normal. Lastly, inspect the water side heat exchanger for fouling; if severe, clean it with oxalic acid and citric acid, or install a cold water pre-filter.
J
Jeff McconnellAug 23, 2025
What should I do if my Arden Heat Pump shows an E06 Low voltage switch failure?
- J
  Jonathan ScottAug 23, 2025
  If your Arden Heat Pump displays an E06 error, follow these steps: First, check the low-pressure pressure switch for damage and verify the wiring terminals are correctly connected to the D12 (blue) port. Then, use a pressure gauge to check for refrigerant loss at the low-pressure inspection port. If needed, add refrigerant and check for leaks at copper pipe welding joints using foam. Next, ensure the fan is working correctly and check the system for blockages. Use a pressure gauge to connect to both high and low pressure inspection ports to measure the system's operating pressure.
S
Stephen SullivanAug 26, 2025
How do I fix an E12 error (Exhaust temperature too high) on my Arden BLN-018TC3?
- K
  Kevin DavisAug 26, 2025
  To address an E12 error on your Arden Heat Pump, start by checking the system for blockages or insufficient refrigerant. Use a pressure gauge to connect to both high and low pressure inspection ports to assess the system's operating pressure. Also, inspect the exhaust gas temperature sensor for damage and use a multimeter to confirm that its resistance value is correct at the T3 (red) port.
L
Larry BrownAug 28, 2025
What does E37 error mean on my Arden BLN-018TC3 and how do I fix it?
- E
  Erika RomeroAug 28, 2025
  If your Arden Heat Pump displays an E37 error, indicating a large temperature difference between inlet and outlet water, follow these steps: First, ensure the pipeline valve is fully open. Next, check if the water pump is working correctly. Then, verify that the pump's rated head and flow meet the machine's operational requirements. Finally, manually drain the drain pump and any air in the pipe.
J
joseph21Aug 30, 2025
Why is my Arden Heat Pump showing an E02 Phase loss fault?
- M
  Max CarrAug 30, 2025
  If your Arden Heat Pump is showing an E02 error, follow these steps: First, check that the power cord is securely connected. Then, use a multimeter to measure whether there is 220V voltage between the neutral wire and each live wire (this should be measured while the power is on). Finally, use a multimeter to measure whether there is 380V voltage between the three live wires (also measured under power-on state). Note that 220V machines will not have this failure.
D
Dr. Kevin VillaSep 1, 2025
What to do if my Arden BLN-018TC3 Heat Pump shows E14 Hot water tank temperature failure?
- S
  Scott RuizSep 1, 2025
  If your Arden Heat Pump displays the E14 error, it indicates a hot water tank temperature sensor failure. This could be due to: 1) an open or disconnected sensor connection line, 2) a damaged sensor, or 3) a damaged motherboard port. You can use a multimeter to measure whether the resistance is correct at the T16 (blue) port.
P
Paul DelgadoSep 3, 2025
What does E15 error mean on my Arden BLN-018TC3 Heat Pump?
- T
  Terry CobbSep 3, 2025
  If your Arden Heat Pump shows an E15 error, it indicates a failure with the inlet water temperature sensor. Possible causes include: 1) an open or disconnected sensor connection line, 2) a damaged sensor, or 3) a damaged motherboard port. Use a multimeter to check if the resistance is correct at the T8 (white) port.
E
Emily HillSep 5, 2025
How do I resolve an E09 Communication failure between the wire controller and the main board on my Arden Heat Pump?
- R
  Rhonda GarnerSep 5, 2025
  To resolve an E09 error on your Arden Heat Pump, first check whether the communication between the wire controller and the main board is normal. Then, use a multimeter to measure whether the voltage output of the motherboard port (white port) is normal.
J
Joy HaleSep 7, 2025
What does E16 Coil sensor failure mean on Arden Heat Pump?
- D
  Diana HardingSep 8, 2025
  If your Arden Heat Pump displays the E16 error, it means there is a coil sensor failure. This may be due to: 1) the sensor connection line being open or disconnected, 2) the sensor being damaged, or 3) the motherboard port being damaged. Use a multimeter to measure whether the resistance value is correct at the TI (red) port.

Summary

Product Introduction

Parameter Table

Lists comprehensive technical specifications and operational parameters for each model.

System Diagrams and Performance Curves

Illustrates system schematics and graphical performance data.

Product Selection and Installation

Product Installation Instructions and Special Precautions

Details essential installation steps and critical safety precautions for the heat pump.

Installation

Covers requirements and procedures for installing the main unit and auxiliary pump.

Pipeline Installation, Water Pressure Commissioning, Pipeline Insulation Requirements

Guides on pipework, pressure testing, and insulation for optimal system performance.

Precautions for Electrical Wiring

Provides essential safety guidelines for proper electrical connections and wiring.

Room Heat Load Calculation

Waterway Antifreeze Protection

Discusses measures and procedures for protecting the water system from freezing.

Electrical Operation

Control

Details the comprehensive control functions and operational logic of the heat pump.

DC Water Pump Control (PWM)

Start Control

Details the conditions and procedures for initiating compressor and unit operation.

Refrigerant Recovery Function

Electric Heating Control EH1;Gas Control Signal Output

Heating Auxiliary Electric Heater EH2

Air Conditioner Secondary Water Pump P_b (Secondary System)

Winter Frost Protection

Covers preventative measures and control logic for protecting against freezing.

Host Water Flow Switch Protection

Details protection mechanisms related to water flow switches and low flow.

Protection Against Excessive Temperature Difference Between Inlet and Outlet Pipes

Explains protection against significant temperature differences in water pipes.

High Voltage Protection

Describes the system's protective measures against high voltage conditions.

Low Voltage Protection

Describes the system's protective measures against low voltage conditions.

Exhaust Temperature Too High Protection

Explains protection against excessively high exhaust gas temperatures.

Display and Operation of the Wire Controller

Wire Controller Interface Display and Operation

Details the display layout, icons, and basic operational procedures of the wire controller.

Setting and Operation of Unit Tooling Number

Factory Parameter Setting Method

Details the procedure for accessing and modifying factory default parameters.

Touch Screen Controller Operation

Wired Controller LCD Display

Covers the initial power-on display, language selection, and basic interface.

Remote Control Operation

Explains the operation of the remote control's power button and mode selection menu.

Function Menu

Details how to access and operate various unit functions like timing control and sterilization.

Query Menu

Setting Menu

Setting Method of Pump Flow Range Setting Value

Host Unit Port Definition Diagram

Provides a comprehensive overview of port definitions for the host unit.

Main Control Board Port Definition Diagram (AP1)

Details the pinout and function of the main control board's ports.

Port Definition Diagram of Water Pump Expansion Board (AP3)

Port Definition Diagram of Switching Power Supply (AP4)

Compressor Driver Board Port Definition Diagram (AP4)

Details the port definitions and connections for the compressor driver board.

Fault Code and Fault Reason

Troubleshooting and Error Causes

Lists common fault codes with detailed troubleshooting steps and potential causes.

Error Diagnosis and Treatment

Model Disassembly and Parts

Provides step-by-step visual instructions for disassembling units and identifying components.

Troubleshooting and Maintenance of Common Fault Codes

Offers detailed guidance on diagnosing and resolving common fault codes encountered during operation.

Arden BLN-018TC3 Specifications

General

Brand	Arden
Model	BLN-018TC3
Category	Heat Pump
Language	English
