ARDES AR5D41PRW - Technical Informations

14
1. Screw and washers
2. Weight of the plastic base
3. Base
4. Lower rod
5. Upper rod
6. Control panel
7. Motor
8. Motor shaft
9. Back grille
10. Lock ring of the back grille
11. Fan
12. Lock ring of the fan
13. Lock ring
14. Front grille
15. Safety screw
16. Remote control
1
2
3
4
5
6
7891011
12
1314
15
16
Technical informations
