7
6. Troubleshooting / error indicator
In the event of an error, the LED display flashes green and orange alternately. There are three different error-displays:
7. Accessories
Further possible errors when using the unit
• Weak or absent vacuum:
Disconnect the Pumpset from the unit. Partly close the connector opening (f) with a finger to test the suction.
How ever, be careful not to completely cover the opening. If suction is detectable, then the pump is working. Test
the Pumpset in accordance with the separate Operating Instructions (only use the original Ardo Pumpset).
• The pump is not working / no data on the display:
Check the mains supply; if the unit still does not work it is defective.
• In the event that one of these errors occurs, and is confirmed, the unit must be brought or sent back to the point
of sale. The unit must be checked out by trained service personnel, or by the manufacturer of the pump unit.
Mains adapter 120 V / 60 Hz output 9 V 1.2 A UL 63.00.69
Regulated mains adapter 100-240 V 50/60 Hz, output 9 V 1.4 A Euro 63.00.141
Regulated mains adapter 100-240 V 50/60 Hz, output 9 V 1.4 A UK 63.00.142
Regulated mains adapter 100-240 V 50/60 Hz, output 9 V 1.4 A UL 63.00.143
Regulated mains adapter 100-240 V 50/60 Hz, output 9 V 1.4 A Australia 63.00.144
Regulated mains adapter 100-240 V 50/60 Hz, output 9 V 1.4 A China 63.00.145
UpgradeSet 63.00.41
Nursing-aids bag 63.00.81
Pumpset bag 63.00.83
Calypso bag 63.00.84
Cold bag - complete 63.00.82
Cooling element 63.00.116
Miscellaneous Pumpsets www.ardomedical.com
General error (time-out)
• Switch off the unit and re-start. If the error message appears again, the unit is
defective and cannot be repaired.
Voltage too low
• Weak batteries
• Incorrect or defective mains adapter
Voltage too high
• Incorrect or defective mains adapter
en
