Arduino® Nano 33 IoT
6 / 17
Arduino® Nano 33 IoT
Modified: 15/06/2022
3 Functional Overview
3.1 Board Topology
Board topology top
Ref.
Description
Ref.
Description
U1
ATSAMD21G18A Controller
U3
LSM6DSOXTR IMU Sensor
U2
NINA-W102-00B WiFi/BLE Module
U4
ATECC608A-MAHDA-T Crypto Chip
J1
Micro USB Connector
PB1
IT-1185-160G-GTR Push button
Board topology bottom
5
7
