Arduino® Nano 33 BLE Rev2

5 / 14 Arduino® Nano 33 BLE Rev2 Modiﬁed: 27/02/2024

2 Functional Overview

2.1 Board Topology

Top:

Board topology top

Ref. Description Ref. Description

U1 NINA-B306 Module Bluetooth® Low Energy 5.0 Module U6 MP2322GQH Step Down Converter

U2 BMI270 Sensor IMU PB1 IT-1185AP1C-160G-GTR Push button

U7 BMM150 Magnetometer IC DL1 Led L

SJ5 VUSB Jumper

Bottom:

Board topology bot

Questions and Answers:

Need help?

Do you have a question about the Arduino Nano 33 BLE Rev2 and is the answer not in the manual?

Arduino Nano 33 BLE Rev2 Specifications

General
