Arduino Nano 33 BLE Sense Rev2 User Manual

Arduino® Nano 33 BLE Sense Rev2
3 / 19 Arduino® Nano 33 BLE Sense Rev2 Modified: 12/01/2023
LPS22HB (Barometer and temperature sensor)
260 to 1260 hPa absolute pressure range with 24 bit precision
High overpressure capability: 20x full-scale
Embedded temperature compensation
16-bit temperature data output
1 Hz to 75 Hz output data rateInterrupt functions: Data Ready, FIFO flags, pressure thresholds
HS3003 Temperature & humidity sensor
0-100% relative humidity range
Humidity accuracy: ±1.5%RH, typical (HS3001, 10 to 90%RH,25°C)
Temperature sensor accuracy: ±0.1°C, typical
Up to 14-bit humidity and temperature output data
APDS-9960 (Digital proximity, Ambient light, RGB and Gesture Sensor)
Ambient Light and RGB Color Sensing with UV and IR blocking filters
Very high sensitivity – Ideally suited for operation behind dark glass
Proximity Sensing with Ambient light rejection
Complex Gesture Sensing
MP34DT06JTR (Digital Microphone)
AOP = 122.5 dbSPL
64 dB signal-to-noise ratio
Omnidirectional sensitivity
–26 dBFS ± 3 dB sensitivity
MP2322 DC-DC
Regulates input voltage from up to 21V with a minimum of 65% efficiency @minimum load
More than 85% efficiency @12V
