Page #2 background imageLoading...
Page #2 background image
Arduino® Nano 33 BLE
2 / 15 Arduino® Nano 33 BLE / Rev. 01 - 26/11/2021
Features
NINA B306 Module
Processor
64 MHz Arm® Cortex-M4F (with FPU)
1 MB Flash + 256 KB RAM
Bluetooth 5 multiprotocol radio
2 Mbps
CSA #2
Advertising Extensions
Long Range
+8 dBm TX power
-95 dBm sensitivity
4.8 mA in TX (0 dBm)
4.6 mA in RX (1 Mbps)
Integrated balun with 50 Ω single-ended output
IEEE 802.15.4 radio support
Thread
Zigbee
Peripherals
Full-speed 12 Mbps USB
NFC-A tag
Arm CryptoCell CC310 security subsystem
QSPI/SPI/TWI/I²S/PDM/QDEC
High speed 32 MHz SPI
Quad SPI interface 32 MHz
EasyDMA for all digital interfaces
12-bit 200 ksps ADC
128 bit AES/ECB/CCM/AAR co-processor
LSM9DS1 (9 axis IMU)
- 3 acceleration channels, 3 angular rate channels, 3 magnetic field channels
- ±2/±4/±8/±16 g linear acceleration full scale
- ±4/±8/±12/±16 gauss magnetic full scale
- ±245/±500/±2000 dps angular rate full scale
- 16-bit data output
MPM3610 DC-DC
Regulates input voltage from up to 21V with a minimum of 65% efficiency @minimum load
More than 85% efficiency @12V
