General| Operating Voltage | 5V |
|---|---|
| Input Voltage | 6-24V |
| Digital I/O Pins | 14 |
| PWM Pins | 6 |
| Analog Input Pins | 6 |
| Flash Memory | 256 KB |
| SRAM | 32 KB |
| EEPROM | 8 KB |
| Clock Speed | 48 MHz |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| USB Connector | USB-C |
| Dimensions | 68.6 mm x 53.4 mm |
| DC Current per I/O Pin | 8 mA |
| UART | Yes |
| SPI | Yes |
| I2C | Yes |
| CAN | No |
| Microcontroller | RA4M1 (Arm Cortex-M4) |
Identifies intended users and applications, including makers, beginners, and educational purposes.
Details the RA4M1 MCU, its clock speed, operating voltage, memory, and key peripherals like DAC and MPU.
Describes the ESP32-S3 module, its dual-core processor, Wi-Fi/Bluetooth capabilities, and operating voltage.
Covers operating voltage, input voltage, USB-C power, and communication interfaces like UART, SPI, I2C, CAN.
Highlights entry-level projects, IoT applications, and the programmable LED matrix feature for projects.
Lists other Arduino UNO series products such as UNO R3, UNO R3 SMD, and UNO R4 Minima.
Details the components and connectors visible on the front of the Arduino UNO R4 WiFi board.
Illustrates the power distribution from input sources (VIN, USB-C) through regulators to board components.
Details the operating voltages for the UNO R4 WiFi (5V) and ESP32-S3 module (3.3V).
Specifies the safe current handling capacity of the RA4M1 microcontroller GPIOs (8mA).
Lists analog pins, their functions (input, DAC, OPAMP), and associated MCU pins.
Details digital pins, their functions (GPIO, PWM, I2C, SPI, UART, CAN) and associated MCU pins.
Details the function of the OFF pin for power control and the ICSP header for programming/debugging.
Instructions for setting up and using the Arduino Desktop IDE for programming the board.
Guidance on using the online Arduino Web Editor for coding and uploading sketches to the board.
Information on leveraging Arduino IoT Cloud for monitoring, logging, and automating IoT projects.
Steps for recovering the board if a sketch causes it to become unresponsive via USB.
