Areva DXC 5000 - Page 21

Installation DXC5K/EN IN/A22
DXC 5000 Page 19/34
RJ21X PIN
(t(teleco 50 PIN)
RJ21X PIN
(t (teleco 50PIN)
LEFT Card
Line No
Ring T Tip
RIGHT Card
Line No
Ring Tip
Line 1 1 26 Line 1 13 38
Line 2 2 27 Line 2 14 39
Line 3 3 28 Line 3 15 40
Line 4 4 29 Line 4 16 41
Line 5 5 30 Line 5 17 42
Line 6 6 31 Line 6 18 43
Line 7 7 32 Line 7 19 44
Line 8 8 33 Line 8 20 45
Line 9 9 34 Line 9 21 46
Line 10 10 35 Line 10 22 47
Line 11 11 36 Line 11 23 48
Line 12 12 37 Line 12 24 49
TABLE 18: RJ21X CONNECTOR PIN ASSIGNMENT – 24 FXS/ FXO CARD
RJ21X PIN
(t(teleco 50 PIN)
RJ21X PIN
(t(teleco 50PIN)
LEFT Card
Line No
L2 T L1
RIGHT Card
Line No
L2 L1
Line 1 1 26 Line 1 13 38
Line 2 2 27 Line 2 14 39
Line 3 3 28 Line 3 15 40
Line 4 4 29 Line 4 16 41
Line 5 5 30 Line 5 17 42
Line 6 6 31 Line 6 18 43
Line 7 7 32 Line 7 19 44
Line 8 8 33 Line 8 20 45
Line 9 9 34 Line 9 21 46
Line 10 10 35 Line 10 22 47
Line 11 11 36 Line 11 23 48
Line 12 12 37 Line 12 24 49
TABLE 19: RJ21X CONNECTOR PIN ASSIGNMENT – 24 MAG CARD
NOTE: Module of w/L1, L2 and w/L1, GND cannot use for 24-MAG Card. It
can use Module of w/L1, L2 or w/L1, GND only. (refer to -ordering
information).
