Pin Number Signal Source
11 External Clock Return DTE
12 Transmit Clock Return DCE
13 Clear To Send Return DCE
14 Transmit Data Return DTE
15 Transmit Clock DCE
16 Receive Data Return DCE
17 Receive Clock DCE
18 Local Loopback DTE
19 Request To Send Return DTE
20 Data Terminal Ready DTE
21 Remote Loopback DTE
22 Data Set Ready Return DCE
23 Data Terminal Ready Return DTE
24 External Clock DTE
25 Test Mode DCE
TABLE 31: V.36/ EIA530/ DB25 DTE PORT PIN DEFINITION
Pin Number Signal Source
1 Cable Shield
2 Transmit Data DTE
3 Control DTE
4 Receive Data DCE
5 Indication DCE
6 Signal Timing DCE
7 External Clock DTE
8 Signal Ground
9 Transmit Data Return DTE
10 Control Return DTE
11 Receive Data Return DCE
12 Indication Return DCE
13 Signal Timing Return DCE
14 External Clock Return DTE
15 Unassigned
TABLE 32: X.21/V.11 AND DB15 DTE PORT PIN DEFINITION
