DXC5K/EN IN/A22 Installation
Page 28/34
DXC 5000
Pin Number Signal Source
1 Cable Shield
2 Transmit Data DTE
3 Receive Data DCE
4 Request To Send DTE
5 Clear To Send DCE
6 Data Set Ready DCE
7 Signal Ground
8 Data Carrier Detect DCE
9 Unassigned
10 Unassigned
11 Unassigned
12 Unassigned
13 Unassigned
14 Unassigned
15 Transmit Clock DCE
16 Unassigned
17 Receive Clock DCE
18 Local Loopback DTE
19 Unassigned
20 Data Terminal Ready DTE
21 Remote Loopback DTE
22 Unassigned
23 Unassigned
24 External Clock DTE
25 Test Mode DCE
TABLE 33: RS232/DB25 DTE PORT PIN DEFINITION
Pin Number Signal Source
1 Transmit Data TIP_Port 1
2 Receive Data TIP_Port 1
3 Unassigned
4 Transmit Data TIP_Port 2
5 Receive Data TIP_Port 2
6 Unassigned
7 Transmit Data TIP_Port 3
8 Receive Data TIP_Port 3
9 Unassigned
10 Transmit Data TIP_Port 4
11 Receive Data TIP_Port 4
12 Unassigned
