Installation DXC5K/EN IN/A22
DXC 5000 Page 33/34
FXS Card Default Configuration
Item Option/ Range Default
A/ µ Law A Law, µ Law A Law
Impedance 600 ohm, 900 ohm 600 ohm
Tx Gain -21 to +10 dB -3 dB
Rx Gain -21 to +10 dB -3 dB
PLAR Ring
Cadence
2" on 4" off, 1" on 2" off 2" on 4" off
Ring Frequency 16.7, 20, 25, 50 Hz 20 Hz
Metering Pulse On, Off Off
Metering Pulse
Frequency
12 KHz, 16 KHz 16 KHz
Metering Level 1Vrms, 2.4Vrms 2.4Vrms
PLAR On, Off Off
FXO Card Default Configuration
Item Option/ Range Default
A/ µ Law A Law, µ Law A Law
Impedance 600 ohm, 900 ohm 600 ohm
Tx Gain -21 to +10 dB -3 dB
Rx Gain -21 to +10 dB -3 dB
Trunk Condition On hook, Off hook On hook
Line Polarity Normal, Reverse Normal
Metering Pulse
Frequency
12 KHz, 16 KHz 16 KHz
Metering Pulse
Detect Mode
Normal, Packet Normal
Metering Pulse
Decode Level
-19 to -47 dBm -27 dBm
Magneto Card Default Configuration
Item Option/ Range Default
Ring Mode Ring across L1 & L2 and L1 &
GND
A/ µ Law A Law, µ Law A Law
Impedance 600 ohm, 900 ohm 900 ohm
Tx Gain -21 to +10 dB -3 dB
Rx Gain -21 to +10 dB -3 dB
PLAR Ring
Cadence
2" on 4" off, 1" on 2" off 1" on 2" off
PLAR On, Off Off
