1. Wireless remote control unit
2. Signaling LEDs and receiver
3. Supply air deflector
4. Air intake grille (removable)
5. Air filter
6. Electric cable with plug
7. Air inlet hole with fan
8. Air outlet hole
9. Condensate discharge
10. Service cap for emergency condensate discharge
11. Operation button
2 - PRESENTATION
2
3
4
5
7
2.1 - DESCRIPTION OF THE PARTS
6
8
10
11
9
1
