Argo CHARM Series - Page 36

78
V 09/22
tubo
pipe
limatrice
file
verso il basso
downwards
3. Secure an insulating tube
4. Install a union nut
• Remove the union nut on the
indoor connecting pipe and outdoor valve.
tall the union nut on the pipe.
Check the quality of the expanded port. If defective, expand
the port again following the procedure described above.
superficie liscia
smooth surface
allargamento imperfetto
defective expansion
lunghezza uguale
equal length
inclinato
slanted
superficie danneggiata
surface damaged
fessurazione
cracked
spessore irregolare
uneven thickness
tubo di raccordo
union pipe
tubo
pipe
REGULATION (EU) No. 517/2014 - F-GAS
The unit contains R32, a fluorinated greenhouse gas with global warming potential (GWP) = 675. Do not release R32
into the atmosphere.
