Argo DADOS 9 PLUS User Manual

5
Specification
2. Specification
Model
DADOS 9 PLUS DADOS 13 PLUS DADOS XL
Nameplate marking
Power supply
Ph-V-
Hz
1φ,220V-240V~50Hz
Cooling Capacity W 2200/2300 2900/3000 3100/3200
Cooling Power consumption W 820 1100 1100
Heating Power consumption W 625 925 960
Cooling EER/COP W/W 2.70/3.70 2.60/3.10 2.80/3.30
System data
Refrigerant type g R410A/430g R410A/620g R410A/805g
Design pressure (Hi/Lo) bar 33.5/10.5. 34.0/11.2 32.5/11.4
Moisture Removal(30°C,RH80%)
L/DAY 30 50 55
air flow (Hi/Mi/Lo) m³/h 280/300/350 290/310/360 290/360/420
Noise level (Hi/Mi/Lo) dB(A) 40/37/38 42/39/38 48/43/40
Dimension&Weight
Dimension (WxDxH) mm W500xD500xH540
Packing (WxDxH) mm W570xD570xH660
Net/Gross weight kg 29/32.7 32/36.3 34/38.5
System Details
Compressor
Model
KRRC072ELJC-A KA-C098ELBC-E
Type
Rotary
Capacity W 1665W±5% 2268W±5%
Input W 655W±5% 855W±5%
Rated current(RLA) A 2.85A±5% 3.8A±5%
Locked rotor Amp(LRA) A 21.1A±5% 20A±5%
Thermal protector B125-140-241C T0705/46
Capacitor 20uF 450V 25uF 450V
Refrigerant oil CC 240 300
Fan Motor
Model MD99-3 MD97-3
Input W 85/44/32 138/113/92
Capacitor 5uF 450V
Lower speed Capacitor Mi N/A 10uF 450V 950Rpm
Lower speed Capacitor Lo N/A 15uF 450V 780Rpm
Speed(hi/mi/lo)
±50
Rpm
1030/830/730 1310/1220/1120
Evaporator
Number of rows 2 3 3
Tube pitch(a)x row pitch(b) mm 21x12.7
Fin spacing FPI 18
Fin type Hydrophilic aluminum
Tube outside dimension type Ф7 inner groove tube
Axial length x height x width mm 317.7x336x25.4 317.7x336x38.1 317.7x336x38.1
Number of circuits 2 2 2
Condenser
Number of rows 2 3 4
Tube pitch(a)x row pitch(b) mm 21x12.7
Fin spacing FPI 18
Fin type aluminum
Tude outside dimension type mm Ф7 inner groove tube
Axial length x height x width mm 400x357x38.1 400x357x50.8 400x357x63.5
Number of circuits 1 1 1
The standard is EN14511 -2:2007 test condition is 35°C db/ 24°C wb

Argo DADOS 9 PLUS Specifications

General

Brand	Argo
Model	DADOS 9 PLUS
Category	Air Conditioner
Language	English
